Slip-On Flange, 12 in Nominal, 19 in OD, 316L Stainless Steel, Raised Face, 150 lb MPN:FLS61RFSO1200
Free Shipping
In Stock
Upgrade your piping systems with the ZORO SELECT - FLS61RFSO1200, a 12-inch stainless steel slip-on flange designed for gas, non-potable water, and oil applications. This durable flange features a raised face and is constructed from 316L stainless steel for exceptional corrosion resistance. With a pressure rating of 150 psi, it's perfect for use in high-pressure piping systems. Its slip-on design makes installation easy, and the flange's larger bore accommodates pipes with larger outside diameters. Ideal for use in industrial settings, this flange is a reliable and long-lasting solution for a variety of piping applications.
Top product features:
- The flange features a bore slightly larger than the pipe outside diameter, facilitating placement over pipes with a bore larger than the outside diameter.
- The flange is typically installed using recommended welding procedures.
- Manufactured from 316L stainless steel, which offers corrosion resistance in compatible applications.
Top product applications:
- Gas piping systems
- Non-potable water piping systems
- Oil piping systems
The ZORO SELECT - FLS61RFSO1200 is a 12-inch stainless steel slip-on flange rated for use with pipes conveying gas, non-potable water, and oil. It features a bore slightly larger than the pipe outside diameter, facilitating placement over pipes with a bore larger than the outside diameter. The flange is typically installed using recommended welding procedures. It is rated for piping systems up to 150 psi. Manufactured from 316L stainless steel, which offers corrosion resistance in compatible applications.
Key Features:
- - Nominal Pipe Size: 12 in
- - Material Grade: 316L Stainless Steel
- - Pressure Class: 150 (rated for operation up to 150 psi at specified conditions)
- - Connection Type: Slip-On, compatible with pipes of specified dimensions
- - Connection Surface: Raised Face
- - Flange Outside Diameter: 19 in
- - Number of Bolt Holes: 24
- - Specific Fitting Shape: Slip On
- - Applicable Standards: ASME B16.5
- ASTM A182
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 15 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 19.00
- Package Width: 19.00
- Package Height: 1.50
- Package Weight: 64.50
