2 in 304 Stainless Steel Blind Flange, Class 300, Raised Face, 8 Bolt Holes, 6.5 in OD MPN:4381003440

The ZORO SELECT - 4381003440 is a forged blind flange made of 304/304L forged stainless steel, designed to close off the end of a piping system. This solid, flat flange is bolted to a mating flange with a gasket, providing a sealed termination point that enables corrosion-resistant pressure containment. The flange features a gasket surface suitable for sealing applications. It has a raised face connection surface and a bolted connection type, with bolt holes for disassembly in accordance with standard practices. The flange conforms to ASTM-SA182 and ANSI B16.5 standards.

Key Features:

• - Material: Forged 304/304L stainless steel
• - Nominal pipe size: 2 inches
• - Flange outside diameter: 6 1/2 inches
• - Flange thickness/overall length: 7/8 inch
• - Pressure rating: Class 300 (Rated for use within the specified pressure ranges for Class 300 applications.)
• - Maximum steam pressure rating: 300 psi
• - Number of bolt holes: 8
• - Bolt circle diameter: 5 inches
• - Bolt hole diameter: 3/4 inch
• - Connection surface: Raised face
• - Connection type: Bolted
• - Product standards: ASTM-SA182, ANSI B16.5
