Hex Head Plug, 1/4 in, 304 Stainless Steel, MNPT, Class 150, 300 psi Max Pressure MPN:40HP112N014
The ZORO SELECT - 40HP112N014 is a reliable and versatile hex head plug designed to close off the end of a pipe, fitting, or port in various industrial applications. Made from 304 stainless steel, it offers resistance to corrosion and high-temperature performance. With a Class 150 pressure rating and maximum operating pressure of 300 psi, it provides secure sealing in high-pressure systems. Suitable for use in chemical processing, oil and gas, and other industries, this plug is ideal for applications where a reliable and durable seal is critical. Its compact design and easy installation make it a valuable addition to any plumbing or piping system.
Top product features:
- 304 stainless steel construction
- Six-sided hex head allows for wrench tightening or removal
- Rated for Class 150 service with a maximum operating pressure of 300 psi
Top product applications:
- Pipe repair or replacement
- Filling of pipe ends or ports
- Pressure testing
The ZORO SELECT - 40HP112N014 is a hex head plug made from 304 stainless steel, designed to close off the end of a pipe, fitting, or port. It features a six-sided hex head which allows it to be tightened or removed with a wrench. This fitting is rated to Class 150 standards and rated for Class 150 service with a maximum operating pressure of 300 psi. It has a nominal pipe size of 1/4 inch and a pipe schedule rating of 40. Operating temperature range: -20 to 350 °F. It conforms to ASTM-A-351 material standards, ANSI/ASME B1.20.1 threading, and MSS-SP-114 Class 150 pressure ratings. Key Features:
- - Material: 304 stainless steel.
- - Type: Hex head plug with a 3-inch hex drive style.
- - Connection: 1/4-inch MNPT threaded fitting, Side A threading size 18.
- - Pressure Rating: Class 150 with a maximum operating pressure of 300 psi.
- - Temperature Range: -20 to 350 °F.
- - Dimensions: Outside diameter 1/4 inch and overall length 23 mm.
- - Standards compliance: ASTM-A-351, ANSI/ASME B1.20.1, MSS-SP-114 Class 150.
- - Does not include pre-applied thread sealant or additional seals.
- - Not magnetic.
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 0.90
- Package Width: 0.70
- Package Height: 0.70
- Package Weight: 3.50
