45° Elbow, 1/4 in FNPT, 304 Stainless Steel, Class 150 MPN:404E111N014

The ZORO SELECT - 404E111N014 is a 45 Degree Elbow stainless steel pipe fitting designed to change the direction of flow by 45 degrees. Material: 304 stainless steel. It features female-threaded connections on both ends with National Pipe Thread (NPT) type, sized at 1/4 inch nominal pipe size for each end. The fitting is rated for a maximum operating pressure of 300 psi and a maximum steam pressure of 150 psi, classified under Class 150 pressure rating. Media compatibility: air, natural gas, non-potable water, oil, potable water, and steam (per Class 150 rating).

Key Features:

• - Material: 304 stainless steel
• - Shape: 45 Degree Elbow
• - Connection Type: Female NPT on both ends
• - Nominal Pipe Size: 1/4 inch for Side A and Side B
• - Pipe Threading: 18 threads per inch on both sides
• - Pressure Rating: Class 150 with max operating pressure of 300 psi
• - Maximum Steam Pressure: 150 psi
• - Suitable Applications: Air, Natural Gas, Non-Potable Water, Oil, Potable Water, Steam
• - Color: Silver
• - Does not include pre-applied thread sealant or seals
• - Meets ASTM-A-351 material standards, ASME B1.20.1 threading standards, and MSS-SP-114 Class 150 pressure rating
