1/4 in FNPT 304 Stainless Steel Cap, Class 150, 300 psi Max Pressure MPN:40RDC111N014
Protect your pipes with the 1/4 in FNPT 304 Stainless Steel Cap, Class 150, 300 psi Max Pressure from GoVets Select. This reliable pipe cap seals the end of a 1/4-inch pipe, preventing flow and protecting the interior from corrosion and damage. Ideal for use in a variety of applications, including plumbing, HVAC, and industrial processes, this cap ensures a secure and leak-free connection. Constructed from durable 304 stainless steel, it withstands high pressures and temperatures, making it perfect for use in demanding environments. With its easy installation and long-lasting performance, this pipe cap is a must-have for any professional or DIY project.
Top product features:
- 304 stainless steel construction provides corrosion resistance and durability.
- FNPT threads of 18 TPI ensure a secure and leak-free connection.
- A maximum operating pressure of 300 psi allows for high-pressure applications.
Top product applications:
- Stainless steel pipe caps are often used in high-temperature applications such as chemical processing and power generation.
- They are also used in applications where corrosion resistance is critical, such as in the food and beverage industry.
- Stainless steel pipe caps are used in applications where a high level of pressure is present, such as in oil and gas production.
The ZORO SELECT - 40RDC111N014 is a stainless steel pipe cap designed to close and seal the end of a 1/4-inch pipe, preventing flow and protecting the pipe interior. Constructed from 304 stainless steel, with FNPT threads of 18 TPI, it functions as a pipe cap designed to close and seal pipe ends. It is rated for Class 150 pressure, with a maximum pressure of 300 psi and maximum steam pressure of 150 psi. The fitting conforms to ASTM-A-351, ANSI B1.20.1, and MSS-SP-114 Class 150 standards. It is rated for operation within the specified temperature range of -20 to 350°F.
Key Features:
- - Material: 304 stainless steel
- - Pipe Size: 1/4 inch nominal size with 1/4 inch outside diameter and 22 mm overall length
- - Connection: Female National Pipe Tapered Threads (FNPT), 18 TPI thread size
- - Pressure Rating: Class 150, maximum operating pressure 300 psi, maximum steam pressure 150 psi
- - Thread Sealant: No pre-applied thread sealant included
- - Included Seal: No sealing component included
- - Standards: ASTM-A-351, ANSI/ASME B1.20.1, MSS-SP-114 Class 150
- - Operating Temperature Range: -20 to 350 degrees Fahrenheit
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 0.70
- Package Width: 0.90
- Package Height: 0.90
- Package Weight: 0.05
