3 in 316 Stainless Steel Socket Weld 90° Elbow, Class 150, ASTM A351, ANSI B16.5 MPN:609E111SW030

• The ZORO SELECT - 609E111SW030 is a 3-inch, 90 Degree Elbow stainless steel pipe fitting designed to connect two pipes at a right angle, creating a 90° change in flow direction. Constructed from 316 stainless steel, it is compatible with air, natural gas, non-potable water, oil, potable water, and steam within the Class 150 pressure rating and Schedule 40 pipe compatibility. This elbow features Socket weld end connections on both ends

• no external threads. It complies with low lead requirements for potable water systems. The fitting is rated Class 150 for pressure
• compatible with Schedule 40 pipe.

  Key Features:

  • - Material: 316 Stainless Steel
  • - Size: 3 in nominal pipe size for both ends
  • - Shape: 90 Degree Elbow for a right-angle flow direction change
  • - Connection type: Socket weld end connections on both ends
  • no external threads
  • - Pressure rating: Class 150
  • - Applications: Intended for use with air, natural gas, non-potable water, oil, potable water, and steam within the specified pressure rating and temperature ranges (Class 150) and Schedule 40 standards
  • - Standards: Material conforms to ASTM-A-351
  • dimensions conform to ANSI B16.5
  • meets MSS-SP-51 Class 150LB for general dimensions, pressure, and temperature ratings
  • - Color: Silver
  • - Includes no pre-applied thread sealant or seals
