Reducing Coupling, 304 Stainless Steel, 1/2 in x 1/4 in FNPT, Class 150, 300 psi MPN:40RC111N012014

The ZORO SELECT - 40RC111N012014 is a stainless steel reducing coupling that connects 1/2" (Side A) x 1/4" (Side B) nominal pipe sizes with female NPT threads on both ends. Constructed from 304 stainless steel and finished in silver, it features female NPT threaded connections on both ends. Rated for Class 150 pressure and a maximum operating pressure of 300 psi, this reducing coupling supports applications conveying air, natural gas, non-potable water, oil, potable water, and steam. The fitting meets ASTM-A-351 material standards, ANSI/ASME B1.20.1 thread specifications, and MSS-SP-114 Class 150 pressure requirements.

Key Features:

• - Material grade: 304 stainless steel
• - Connection type: Female NPT threads on both ends
• - Nominal pipe sizes: 1/2" (Side A) x 1/4" (Side B)
• - Pressure rating: Class 150 with maximum operating pressure of 300 psi
• - Suitable for conveying air, natural gas, non-potable water, oil, potable water, and steam
• - Complies with lead content requirements for potable water use per applicable standards
• - Overall length: 44 mm
• - Does not include pre-applied thread sealant or sealing components
