Circuit Breaker 100A 3P 347/600VAC FBN MPN:FBN36TE100R

FB-frame GE molded case circuit breakers are rated up to 100A and interrupt excessive current flows to protect devices from electrical damage. They're typically used with GE light panels, motor control centers, and panelboards. Their current-carrying parts, mechanisms, and trip devices are contained in a molded case.

Technical Specifications

• Item Molded Case Circuit Breaker
• Amps 100 A
• AC Voltage Rating 347/600V AC
• Max. AIR Rating 150kA at 240V AC
• For Use With GE Panelboards
• Series FBN
• Circuit Breaker Type Standard
• Number of Poles 3
• DC Voltage Rating Not Rated
• Terminal Connection Lug
• Trip Type Thermal Magnetic
• Phase 3
• Instantaneous Trip Fixed
• Phase Connection ABC
• Frame Size 100A/FB
• Circuit Breaker Mounting Style Free Standing
• Height 6.45 in
• Width 4.11 in
• Depth 3.88 in
• Min. Wire Size 4 AWG
• Max. Wire Size 1/0 AWG
• Circuit Breaker Actuator Toggle
• Standards UL Listed

Manufacturer Details

• Manufacturer: GE
• Condensed Mfg Number: FBN36TE100R
• MPN: FBN36TE100R

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: US
• CA Prop 65 Wht Label: N

Classification Details

• Harmonization Code: 8536200020
• GDS Category Name: Molded Case Circuit Breakers
• GDS Family Name: Distribution
• GDS Segment Name: Electrical
• UNSPSC: 39121601
• UNSPSC Class ID: 16
• UNSPSC Commodity Name: Circuit protection devices and accessories
• UNSPSC Commodity ID: 01
• UNSPSC Commodity Name: Circuit breakers
• UNSPSC Family ID: 12
• UNSPSC Family Name: Electrical equipment and components and supplies
• UNSPSC Segment ID: 39
• UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies

Shipping Details

• Not For Sale In: HI AK PR
