K4554 Pressure Gauge -14 to 500 MPN:FLUKE-700RG07
Introducing the Fluke 4554 Digital Compound Gauge -14 to 500 psig, perfect for pressures up to 600 psi (40 bar) when used with PTP-1 pneumatic pump and up to 10,000 psi (690 bar) with HTP-2 hydraulic pump (both sold separately). This reliable and user-friendly gauge offers a large backlit screen displaying three parameters at once, providing you the flexibility to measure different pressures simultaneously. The Fluke 4554 includes logging capabilities that record up to 8,493 pressure measurements for later analysis using 700G/TRACK software (sold separately). Its compact design and lightweight features make it suitable for field service work or any setting where portability is essential. Applications range from HVAC, plant maintenance, to production environments, the Fluke 4554 ensures precision measurements with accuracy and reliability, making it a versatile tool for many industries. With its ease of use and range of features, this digital compound gauge from Fluke is an ideal solution for any professional or DIY enthusiast in need of pressure measurement solutions.
Top product features:
- Logging Capabilities
- Three Parameter Display
- Large Backlit Screen
Top product applications:
- HVAC maintenance and repair
- Industrial pressure testing
- Plant maintenance
Technical Specifications
- Digital Pressure and Vacuum Gauge Type Digital Compound Gauge
- Item Digital Compound Gauge
- Gauge Nominal Dial Size 3 3/4 in
- Basic Gauge Case Material Metal
- Basic Gauge Wetted Parts Stainless Steel
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values -14 to 0 to 500
- Digital Gauge Accuracy +/-0.04% of Reading
- Display Multiline LCD
- Socket Material Stainless Steel
- Case Material Cast ZNAL
- Case Color Yellow
- Digital Gauge Display Units bar, psi
- Powered By (3) AA Batteries
- Agency Compliance CSA: Class 1, Div2, Groups A-D rating, ATEX: rating II 3 G Ex nA IIB T6
- Gauge Operating Temp. Range -14 Degrees to 131 Degrees F
- Series Fluke-700G
- Calibration Certificate NIST Traceable
- Peak Hold No
- Includes Calibration Certificate, Manual On CD, NPT/Metric Adapter, Protective Cover
- Manufacturers Warranty Length 3 yr
Manufacturer Details
- Manufacturer: Fluke
- Condensed Mfg Number: FLUKE700RG07
- MPN: FLUKE-700RG07
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Industrial Process and Test Digital Pressure Gau
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
