K4554 Pressure Gauge -14 to 100 MPN:FLUKE-700RG06
The K4554 Pressure Gauge from Fluke is an essential tool for anyone looking to measure and log pressure readings in a wide range of industrial applications. With its rugged design, large backlit screen, and compatibility with Fluke pneumatic and hydraulic pumps, the K4554 is perfect for those working in high-pressure environments such as automotive repair, manufacturing, and maintenance operations. Its ability to display three parameters at once provides unparalleled measurement flexibility while its logging capabilities allow users to record up to 8,493 pressure measurements for future reference. With the K4554 Pressure Gauge from Fluke, you can take your measuring and logging abilities to the next level in a wide range of industries and applications.
Top product features:
- Rugged and easy-to-use design
- Compatibility with Fluke pneumatic and hydraulic pumps
- Large backlit screen displays three parameters at once
Top product applications:
- High-pressure testing and measurement in automotive repair environments
- Pressure testing of hydraulic systems in manufacturing settings
- Leak detection and diagnostics in aerospace applications
Technical Specifications
- Digital Pressure and Vacuum Gauge Type Digital Compound Gauge
- Item Digital Compound Gauge
- Gauge Nominal Dial Size 3 3/4 in
- Basic Gauge Case Material Metal
- Basic Gauge Wetted Parts Stainless Steel
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values -14 to 0 to 100
- Digital Gauge Accuracy +/-0.04% of Reading
- Display Multiline LCD
- Socket Material Stainless Steel
- Case Material Cast ZNAL
- Case Color Yellow
- Digital Gauge Display Units bar, psi
- Powered By (3) AA Batteries
- Agency Compliance CSA: Class 1, Div2, Groups A-D rating, ATEX: rating II 3 G Ex nA IIB T6
- Gauge Operating Temp. Range -14 Degrees to 131 Degrees F
- Series Fluke-700G
- Calibration Certificate NIST Traceable
- Peak Hold No
- Includes Calibration Certificate, Manual On CD, NPT/Metric Adapter, Protective Cover
- Manufacturers Warranty Length 3 yr
Manufacturer Details
- Manufacturer: Fluke
- Condensed Mfg Number: FLUKE700RG06
- MPN: FLUKE-700RG06
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Industrial Process and Test Digital Pressure Gau
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
