K4554 Pressure Gauge 0 to 300 MPN:FLUKE-700GA27
Introducing the K4554 Pressure Gauge by Fluke, an essential tool for professionals in HVAC maintenance, manufacturing, and other industrial sectors requiring precise pressure measurement. This rugged and easy-to-use gauge offers a complete solution with the 700PTPK or 700HTPK, extending its application range up to 10,000 psi (690 bar). The large backlit screen displays three parameters simultaneously, while logging up to 8,493 pressure measurements for future reference. The gauge's basic case material is made of durable metal, ensuring longevity even in the most demanding environments. With its ability to improve productivity and prevent costly maintenance issues, the Fluke K4554 Pressure Gauge is a must-have tool for any professional in need of accurate pressure measurement.
Top product features:
- Large backlit screen displays up to three parameters simultaneously
- Gauge can log up to 8,493 pressure measurements for future reference
- Durable metal case for improved longevity and tough environments
Top product applications:
- HVAC maintenance and repair professionals who require precise pressure measurements to troubleshoot and maintain equipment.
- Manufacturers of consumer or industrial products that must test for quality control and pressure tolerance levels.
- Technicians working in oil, gas, or chemical industries where accurate and high-pressure readings are essential during plant operations and maintenance.
Technical Specifications
- Digital Pressure and Vacuum Gauge Type Digital Pressure Gauge
- Item Digital Pressure Gauge
- Gauge Nominal Dial Size 3 3/4 in
- Basic Gauge Case Material Metal
- Basic Gauge Wetted Parts Stainless Steel
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 300
- Digital Gauge Accuracy +/-0.05% of Reading
- Display Multiline LCD
- Socket Material Stainless Steel
- Case Material Cast ZNAL
- Case Color Yellow
- Digital Gauge Display Units bar, psia
- Powered By (3) AA Batteries
- Agency Compliance CSA: Class 1, Div2, Groups A-D rating, ATEX: rating II 3 G Ex nA IIB T6
- Gauge Operating Temp. Range -14 Degrees to 131 Degrees F
- Series Fluke-700G
- Calibration Certificate NIST Traceable
- Peak Hold No
- Includes Calibration Certificate, Manual On CD, NPT/Metric Adapter, Protective Cover
- Manufacturers Warranty Length 3 yr
Manufacturer Details
- Manufacturer: Fluke
- Condensed Mfg Number: FLUKE700GA27
- MPN: FLUKE-700GA27
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Industrial Process and Test Digital Pressure Gau
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
