K4554 Pressure Gauge -14 to 2000 MPN:FLUKE-700G10
The K4554 pressure gauge from Fluke is the perfect tool for all your industrial pressure measurement needs. With a range of -14 to 2000 psi (760 bar) and a high-resolution large backlit screen that displays 3 parameters at once, you can get accurate readings even in the toughest environments. Its rugged design and ease of use make it ideal for pressure testing applications such as hydraulics, pneumatics, HVAC, process control, and manufacturing. With the option to log up to 8,493 measurements to memory (requires 700G/TRACK software, sold separately), you can easily document your test results for future reference. Whether you're working in automotive, aerospace, or any industry that relies on pressure testing, the Fluke K4554 is the perfect tool to ensure your equipment is functioning properly and safely.
Top product features:
- Rugged and easy-to-use
- Displays 3 parameters at once
- Can log up to 8,493 pressure measurements
Top product applications:
- Hydraulic Pressure Testing
- Pneumatic Pressure Testing
- Vacuum Pressure Testing
Technical Specifications
- Digital Pressure and Vacuum Gauge Type Digital Compound Gauge
- Item Digital Compound Gauge
- Gauge Nominal Dial Size 3 3/4 in
- Basic Gauge Case Material Metal
- Basic Gauge Wetted Parts Stainless Steel
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values -14 to 0 to 2000
- Digital Gauge Accuracy +/-0.05% of Reading
- Display Multiline LCD
- Socket Material Stainless Steel
- Case Material Cast ZNAL
- Case Color Yellow
- Digital Gauge Display Units bar, psi
- Powered By (3) AA Batteries
- Agency Compliance CSA: Class 1, Div2, Groups A-D rating, ATEX: rating II 3 G Ex nA IIB T6
- Gauge Operating Temp. Range -14 Degrees to 131 Degrees F
- Series Fluke-700G
- Calibration Certificate NIST Traceable
- Peak Hold No
- Includes Calibration Certificate, Manual On CD, NPT/Metric Adapter, Protective Cover
- Manufacturers Warranty Length 3 yr
Manufacturer Details
- Manufacturer: Fluke
- Condensed Mfg Number: FLUKE700G10
- MPN: FLUKE-700G10
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Industrial Process and Test Digital Pressure Gau
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
