Pressure Calibrator -12 to 30 psi MPN:FLUKE-719PRO 30G
The Fluke Pressure Calibrator -12 to 30 psi is a versatile tool designed for professional calibration technicians who need precise and accurate pressure measurements. This compact handheld calibrator features an internal electric pump that generates pressure up to 30psi, making it suitable for testing and calibrating a wide range of pressure instruments such as gauges, transducers, and sensors. The device offers four measurement functions - pressure, mA DC, V DC, and temperature - providing users with comprehensive data analysis options. With its internal pressure measurement range of -12 to 30 psi and internally generated pressure range of -12 to 30 psi, the Fluke Pressure Calibrator is ideal for calibrating various pressure-based systems in a variety of industries, including automotive, HVAC, medical, and manufacturing. Its user-friendly design, ease of use, and accuracy make it an essential tool for anyone who needs to ensure the reliability and safety of their equipment and processes.
Top product features:
- Internal electric pump generates pressure up to 30psi
- Four measurement functions Pressure, mA DC, V DC, Temperature
- Internal pressure measurement range -12 to 30 psi and internally generated pressure range -12 to 30 psi
Top product applications:
- Calibration of pressure instruments such as gauges, transducers, and sensors in industrial and manufacturing settings
- Testing and verifying the accuracy of pressure systems in aerospace, automotive, HVAC, medical devices, and other industries
- Quality control and maintenance of pressure equipment in various settings where precise and accurate pressure measurements are required
Technical Specifications
- Item Handheld Pressure Calibrator
- Pressure Source Internal Electric Pump
- Measurement Functions Pressure, mA DC, V DC, Temperature
- Internal Pressure Measurement Range -12 to 30 psi
- Internally Generated Pressure Range -12 to 30 psi
- Pressure Range with External Modules -15 psi to 10,000 psi
- Internal Pressure Range Accuracy +/-0.035% of Full Scale
- Loop Supply Voltage 24V DC
- Current Measurement Range 0 to 24mA DC
- Source Current 4 to 20mA DC
- Voltage Measurement Range 0 to 30V DC
- RTD Type PT 100, PT 385
- RTD Temperature Range -40 Degrees to 150 Degrees C
- Displayed Pressure Units bar, cm wc, ft wc, in Hg, in wc, kg/sq cm, kPa, mbar, mm Hg, psi
- Display Multiline LCD
- Standards CE, CSA, TUV, KCC, RCM
- Calibration Certificate NIST
- Powered By (8) Alkaline AA Batteries
- Includes Test Leads with Alligator Clips, Printed user's manual and user's manual on CD-ROM in 14 languages, Fluid trap, Carrying case, 1/4 inch NPT to 1/4 inch ISO adapter, Accessory hose kit with (2) 1/8 inch quick fit adapters and 1 meter of hose, Traceable Certificate of Calibration
- Manufacturers Warranty Length 3 yr
- Pressure Modules 700P Series (29 Ranges)
Manufacturer Details
- Manufacturer: Fluke
- Condensed Mfg Number: FLUKE719PRO30G
- MPN: FLUKE-719PRO 30G
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Handheld Pressure Calibrators
- GDS Family Name: Process Monitoring
- GDS Segment Name: Test Instruments
- UNSPSC: 81141504
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Quality control
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Equipment test calibration or repair
- UNSPSC Family ID: 14
- UNSPSC Family Name: Manufacturing technologies
- UNSPSC Segment ID: 81
- UNSPSC Segment Name: Engineering and Research and Technology Based Services
Shipping Details
- Not For Sale In: HI AK PR
