Axial Fan Square 3-1/8 H 30/23 CFM MPN:4WT40
Axial Fan Square 3-1/8 H 30/23 CFM
Buna N o-rings offer excellent sealing capabilities in a variety of applications, their 2.095-inch inner diameter ensures compatibility with various components in numerous industries such as aerospace or automotive requiring reliable solutions. Moreover, the versatile chemical and temperature resistance makes them suitable for use in harsh environments. Additionally, the packaging of 25 pieces offers convenience during installation and storage. Thus, these o-rings find widespread use across various sectors needing robust tools for secure and durable connections.
Standard square axial fans are used in dry locations to cool equipment within an enclosure. These equipment-cooling fans have a square housing that can mount over a round cutout or fit into a square cutout for installation.Square compact axial fans have a square-shaped housing that can span a round cutout or fit into a square cutout for cooling equipment within an enclosure. These equipment-cooling fans require minimal space for installation and are typically installed where there's full access for mounting them against the interior of an enclosure. They have mounting holes at each corner for securing them to a wall or panel.
Technical Specifications
- Item Standard Square Axial Fan
- Fan Shape Square
- Mounting Eye O.C. 2 13/16 in
- Height 3 1/8 in
- Depth 1 1/2 in
- Width 3 1/8 in
- CFM @ 0.000-In. SP 30/23
- Watts 12/14
- Voltage 115V AC
- Hz 60/50
- Amps 0.13/0.15
- Electrical Connection - Fans Lead Wires
- Sound Level 35/31
- IP Rating IP20
- Mounting Position Horizontal
- Bearing Type Sleeve
- RPM 2750/2300
- Motor Design Shaded Pole
- Motor Insulation Class A
- Thermal Protection Impedance
- Max. Ambient Temp. 158 Degrees F
- Blade Material Polybutylene Terephthalate
- Housing Material Cast Aluminum
- Color Black
- Standards RU E19455 AND CSA LR206189
- Environmental Applications Equipment Cooling
Manufacturer Details
- Manufacturer: Dayton
- Condensed Mfg Number: 4WT40
- MPN: 4WT40
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 8414596590
- GDS Category Name: Axial Fans
- GDS Family Name: Cooling Fans and Air Circulators
- GDS Segment Name: HVAC and Refrigeration
- UNSPSC: 40101604
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Air circulation and parts and accessories
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Fans
- UNSPSC Family ID: 10
- UNSPSC Family Name: Heating and ventilation and air circulation
- UNSPSC Segment ID: 40
- UNSPSC Segment Name: Distribution and Conditioning Systems and Equipment and Components
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on June 10, 2023 12:44am UTC
Category: Cooling Fans and Air Circulators
