4 Bolt Flange Bearing Ball 1 3/4in Bore MPN:3FCY2
SKU
226-CXO-3FCY2
4 Bolt Flange Bearing Ball 1 3/4in Bore
This solid carbide round insert, available in a 1/4 inch diameter, is an exceptional choice for precision machining applications requiring high-quality finishes. Its ability to maintain hardness and sharp edges ensures smooth performance even in the most demanding of tasks. Additionally, its longevity far surpasses conventional tools made from HSS or carbon steel, ultimately reducing tooling costs and providing improved results that meet rigorous industry standards across various industries including aerospace, automotive, medical, and electronics- an essential tool for any serious machinist looking to increase efficiency and maintain quality.
Buy Dayton item #3FCY2 from our huge selection of Hardware Accessories to show your support for our ♻ Socially Responsible Veteran-Owned Business.
Technical Specifications
- Item 4-Bolt Flange Bearing
- Mounted Bearing Item 4-Bolt Flange Bearing
- Bearing Insert Type Ball
- Bore Dia. 1 3/4 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Cast Iron
- Bearing Insert Material 52100 Chrome Steel
- Bolt Hole Center-to-Center 4 1/8 in
- Series Standard Duty
- Bolt Size 1/2 in
- Overall Height 2 1/16 in
- Overall Width 5 3/8 in
- Overall Length 5 3/8 in
- Bearing Lubrication Chevron SRI-2 or NLGI #2 Equivalent
- Dynamic Load Capacity 7,157 lb
- Static Load Capacity 4,674 lb
- Temp. Range -20 Degrees to 200 Degrees F
- Finish Painted
- Includes (2) Set Screws, Oiler Cap
- Dimension A 5 3/8 in
- Dimension C 4 1/8 in
- Dimension D 5/8 in
- Dimension F 2 1/16 in
Manufacturer Details
- Manufacturer: Dayton
- Condensed Mfg Number: 3FCY2
- MPN: 3FCY2
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483204040
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171504
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Ball bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
