Screw Machine Drill 1/8 HSS MPN:48508

Discount: See in Cart
Free Shipping
In Stock
Brand: Chicago-Latrobe
Part #: 48508
UPC: 662355485088
SKU
226-CXG-10P147
11.16 for Minimum Order Qty of 4
$2.79
Screw Machine Drill 1/8 HSS

The Screw Machine Drill Bit from Chicago-Latrobe is an essential tool for any precision machinist. These high-speed steel bits are perfect for drilling into metal or plastic with ease, providing precise results every time. With their bright finish and spiral-flute design, these bits are perfect for professionals who need durable and long-lasting tools. The 1/8 inch size makes it perfect for a variety of applications, from aerospace to automotive, while the fractional inch measurement system ensures accurate sizing. Made with high-speed steel, these bits are both strong and resistant to wear, making them a top choice for those who demand the best from their tools. If you're looking for precision and accuracy in your machining projects, the Screw Machine Drill Bit is the perfect choice.

Top product features:

  • Sprial-flute design for chip evacuation
  • Bright finish that resists wear and tear
  • Made of high-speed steel for durability and precision

Top product applications:

  • Aerospace industry for drilling metal parts and materials
  • Automotive manufacturing to precision drill into metal components
  • Machine shops and tooling industries for high-precision machining processes
These drill bits have a bright finish that is not affected when the bits' cutting edges are resharpened. Spiral-flute drill bits evacuate chips as the bits drill into a workpiece.

Technical Specifications

  • Item Screw Machine Drill Bit
  • Drill Bit Size 1/8 in
  • Decimal Equivalent 0.1250
  • Measurement System Fractional Inch
  • Material - Machining High Speed Steel
  • Finish - Machining Bright (Uncoated)
  • Drill Bit Point Angle 118 Degrees
  • Drill Bit Point Type Conventional Point
  • Flute Type Spiral
  • Number of Flutes 2
  • Flute Length 7/8 in
  • Maximum Drilling Depth 7/8 in
  • Helix Angle 28 Degrees
  • Cutting Direction Right Hand
  • Spiral Direction Right Hand
  • Shank Type - Machining Straight
  • Shank Dia. 1/8 in
  • Shank Length 1 in
  • Overall Length 1 7/8 in
  • Depth:Dia. Ratio 4xD
  • Drill Length Class Screw Machine Length
  • Drill Point Length 0.0376 in
  • Drill Bit Grouping Individual
  • Series 157
  • Standards Not Rated
  • Drill Diameter Tolerance +0.0000 in /-0.0005 in
  • Primary Material Application Aluminum, Brass, Bronze, Cast Iron, Copper, Steel
  • Primary Material Application ISO Code K, N, P

Manufacturer Details

  • Manufacturer: Chicago-Latrobe
  • Condensed Mfg Number: 48508
  • MPN: 48508

Label Details

  • Hazardous Material: N
  • Green Material Flag: N
  • Country of Origin: US
  • CA Prop 65 Wht Label: N

Classification Details

  • Harmonization Code: 8207504030
  • GDS Category Name: Screw Machine Length Drill Bits
  • GDS Family Name: Drilling and Holemaking
  • GDS Segment Name: Machining
  • UNSPSC: 27112801
  • UNSPSC Class ID: 28
  • UNSPSC Commodity Name: Tool attachments and accessories
  • UNSPSC Commodity ID: 01
  • UNSPSC Commodity Name: Drill bits
  • UNSPSC Family ID: 11
  • UNSPSC Family Name: Hand tools
  • UNSPSC Segment ID: 27
  • UNSPSC Segment Name: Tools and General Machinery

Shipping Details

  • Not For Sale In: HI AK PR
Related ASINs: B00209I3PI
