Pipe Nipple 1/4 . 10 . Galv Steel MPN:0331008607
SKU
226-CXG-29VF84
Pipe Nipple 1/4 . 10 . Galv Steel
The 25 AWG (American Wire Gauge), 1/2 inch diameter, 15 ft. length braided grounding wire is designed for electrical and electronics applications. The flexible yet durable wire ensures easy installation and use. It's ideal for a variety of grounding tasks, such as connecting grounds to metal cases or chassis, bonding points together in circuit loops, and establishing safety grounds in electrical systems. The braided design of the wire offers excellent conductivity while minimizing the risk of physical damage to the wire, making it a long-lasting solution for grounding needs. Its small diameter also makes it easy to install in tight spaces or when multiple grounding connections are needed.
Has a weld bead inside, is NPT threaded at both ends, and resists rust and corrosion. For low-pressure plumbing applications including air, water, oil, natural gas, and steam. Certified for use in potable water applications. Threads conform to ANSI B1.20.1 standards. Material conforms to ASTM A-53 Type E, Grade A standards. Manufacturing conforms to ASTM A-733 standards.
Technical Specifications
- Item Nipple
- Pipe Connection Type Threaded on Both Ends
- Pipe Type Pipe Nipple
- Pipe Schedule 40
- Material - Pipe Galvanized Steel
- Pipe Weld Type Continuous Weld
- Pipe Size - Nominal 1/4 in
- Overall Pipe Length 10 in
- Pipe Thread Type MNPT x MNPT
- Max. Pressure 150 psi @ 150 Degrees F
- Inside Dia. (In.) 0.364 in
- Outside Dia. (In.) 0.54 in
- Wall Thickness (In.) 0.088 in
- Metal Detectable Yes
- Standards ASTM A-53 Type F, ASTM A733, Grade A
Manufacturer Details
- Manufacturer: Beck
- Condensed Mfg Number: 0331008607
- MPN: 0331008607
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 7307995015
- GDS Category Name: Metal Pipe and Pipe Nipples
- GDS Family Name: Pipe and Tubing
- GDS Segment Name: Plumbing
- UNSPSC: 40142318
- UNSPSC Class ID: 23
- UNSPSC Commodity Name: Pipe fittings
- UNSPSC Commodity ID: 18
- UNSPSC Commodity Name: Pipe nipples
- UNSPSC Family ID: 14
- UNSPSC Family Name: Fluid and gas distribution
- UNSPSC Segment ID: 40
- UNSPSC Segment Name: Distribution and Conditioning Systems and Equipment and Components
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on September 26, 2024 1:02pm UTC
Category: Pipe and Tubing
