K4222 Pressure Gauge 0 to 400 psi 4-1/2In
The single point thread milling cutter is a durable tool featuring an offset for effective threading applications within milling processes. Its small size allows precision operation while minimizing chatter in materials including stainless steel, cast iron, aluminum, or copper with ease. Its cutting diameter measures 5/8 inches shank ensuring versatility when threading across various materials with one inch threads per foot while its construction offers durability under demanding industrial settings suited for professional mechanics or machinists who require quick accurate workpiece operation resulting high precision products saving time and labor cost offering superior finishes ideal for diverse applications.
Chemical and Petroleum Process Gauges• 4-1/2" dial Accuracy: ±0.5% Solid front/blowout back housing 1/2" NPT lower connectionGlycerin-filled models vent for atmospheric pressure and temperature compensation and feature Buna N O-ring seal.
Technical Specifications
- Item Pressure Gauge
- Gauge Application Process
- Gauge Nominal Dial Size 4 1/2 in
- Basic Gauge Case Material Plastic
- Basic Gauge Wetted Parts Stainless Steel
- Gauge Connection Type MNPT
- Gauge Connection Size 1/2 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 400
- Gauge Accuracy +/-0.50%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable Yes
- Gauge Mounting Method Surface
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 50
- Gauge Case Material Phenolic/Thermoplastic
- Gauge Case Color Black
- Basic Gauge Socket Material Stainless Steel
- Gauge Socket Material 316L Stainless Steel
- Basic Gauge Sensor Material Stainless Steel
- Gauge Sensor Material 316L Stainless Steel
- Gauge Lens Material Glass
- Basic Gauge Lens Material Glass
- Operating Temp. Range -50 Degrees to 150 Degrees F
- For Use With Media Compatible with 316L Stainless Steel
- Calibration Certificate Included No
- Series 1259SD
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: 451259SD04L400
- MPN: 451259SD04L400#
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
