K4698 Pressure Transmitter 0 to 7500 psi 1/4 MPN:G17M0242CD7500#
Honeywell's 53 inches inner diameter (ID) x 57 inches outer diameter (OD), with a thickness of 2 inches, fluoroelastomer O-ring is designed for extreme duty applications in various industries that require maximum flexibility and resistance to chemicals. With an unmatched capability to handle high pressure up to 250 PSI along with temperature extremes from -45F up to +325F makes this o-ring ideal for use in hydraulic and pneumatic applications, automotive and aerospace systems among others. This product is backed by Honeywell's legacy of quality and reliability making it the go-to choice for experts worldwide seeking premium-grade sealing solutions. The perfect complement to Honeywells comprehensive line of sealing products, this O-ring enables customers across a broad spectrum of industries to tackle demanding sealing challenges with confidence knowing that they can count on the unsurpassed performance and longevity associated with Honeywell branded products.
Technical Specifications
- Transmitter Type Pressure Transmitter
- Wetted Materials - Transmitters Stainless Steel
- Range Values - Transmitter 0 to 7500
- Range Units - Transmitter psi
- Accuracy - Transmitter +/-0.50% Full Scale
- Electrical Connections - Transmitter 4 Pin Hirschmann Style A DIN 43650-A Connector
- Power Required - Transmitters 9 to 36V DC
- Process Connection Size - Transmitter 1/4 in
- Process Connection Type - Transmitter MNPT
- Output - Transmitter 4 to 20mA DC
- Operating Temp. - Transmitter -40 Degrees to 257 Degrees F
- Wiring Entry - Transmitter 1/2 in FNPT
- Housing 304 Stainless Steel
- Loop Resistance Dependent on Loop Supply Voltage
- Max. Pressure (PSI) 9,000 psi
- Thermal Error +/-3% (-4 Degrees to 185 Degrees F)
- Compatible With Any Process Compatible with 316 Stainless Steel
- Includes Instructions
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: G17M0242CD7500
- MPN: G17M0242CD7500#
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Standard Pressure and Vacuum Transmitters
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112107
- UNSPSC Class ID: 21
- UNSPSC Commodity Name: Transducers
- UNSPSC Commodity ID: 07
- UNSPSC Commodity Name: Electro pneumatic transducers
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
