K4719 Pressure Transmitter -14.7 psi to 30 psi MPN:G17MEK42EWVAC/30#
Introducing our K4719 Pressure Transmitter, designed to cater to your industrial pressure measurement needs with precision and reliability. With its compound transmitter design and stainless steel wetted materials, it offers unmatched durability and corrosion resistance for seamless integration into a wide range of processes. Featuring an impressive -14.7 psi to 30 psi range and accurate +/-0.50% full scale accuracy, it is ideal for monitoring and controlling pressure in various applications such as oil and gas, chemical, pharmaceuticals, and food and beverage industries. The FM and CE approvals ensure its safety and reliability while seamlessly integrating with test instruments for hassle-free calibration and setup. Enhance your process efficiency and safety with our K4719 Pressure Transmitter today!
Top product features:
- Compound transmitter design
- Stainless steel wetted materials
- -14.7 psi to 30 psi range
Top product applications:
- Process control in the oil and gas industry
- Monitoring pressure in chemical processing facilities
- Testing and calibration of pressure equipment
Technical Specifications
- Transmitter Type Compound Transmitter
- Wetted Materials - Transmitters Stainless Steel
- Range Values - Transmitter 30 to 0 to 30
- Range Units - Transmitter in Hg/psi
- Accuracy - Transmitter +/-0.50% Full Scale
- Electrical Connections - Transmitter 4 Pin M12 Connector
- Power Required - Transmitters 9 to 36V DC
- Process Connection Size - Transmitter 7/16"-20
- Process Connection Type - Transmitter SAE Male
- Output - Transmitter 4 to 20mA DC
- Operating Temp. - Transmitter -40 Degrees to 257 Degrees F
- Wiring Entry - Transmitter 1/2 in FNPT
- Housing 304 Stainless Steel
- Loop Resistance Dependent on Loop Supply Voltage
- Max. Pressure (PSI) 60 psi
- Thermal Error +/-3% (-4 Degrees to 185 Degrees F)
- Compatible With Any Process Compatible with 316 Stainless Steel
- Includes Instructions
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: G17MEK42EWVAC30
- MPN: G17MEK42EWVAC/30#
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026204000
- GDS Category Name: Standard Pressure and Vacuum Transmitters
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112107
- UNSPSC Class ID: 21
- UNSPSC Commodity Name: Transducers
- UNSPSC Commodity ID: 07
- UNSPSC Commodity Name: Electro pneumatic transducers
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
