K4232 Pressure Gauge 0 to 600 psi 4-1/2In
The 3-ring binder offers the perfect solution for organizing documents such as reports, printouts or presentations while maintaining a professional appearance with its sleek, white design. With an extra number of pages to hold ample amounts of letters, legal and A4 papers without punching additional holes, it is ideal for those needing large volume storage space. The strong plastic cover provides protection from daily wear and tear while the durable construction ensures easy access to stored documents. As a must-have office supply item, this binder delivers reliable performance for staying organized in busy work environments or personal use.
Process Pressure Gauges with Seals• 4-1/2" dial Accuracy: ±0.5% full scale Solid-front safety housing Seal for corrosive materials compatible with stainless steel or Hastelloy® 1/2" FNPT lower connectionEasily adjustable, self-locking micrometer pointer. For applications that require protection from chemicals and solids that can damage the gauge.
Technical Specifications
- Item Pressure Gauge
- Gauge Application Process
- Gauge Nominal Dial Size 4 1/2 in
- Basic Gauge Case Material Plastic
- Basic Gauge Wetted Parts Stainless Steel
- Gauge Connection Type FNPT
- Gauge Connection Size 1/2 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 600
- Gauge Accuracy +/-0.50%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable Yes
- Gauge Mounting Method Surface
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 5
- Gauge Case Material Thermoplastic
- Gauge Case Color Black
- Basic Gauge Socket Material Stainless Steel
- Gauge Socket Material 316 Stainless Steel
- Basic Gauge Sensor Material Stainless Steel
- Gauge Sensor Material 316 Stainless Steel
- Gauge Lens Material Glass
- Basic Gauge Lens Material Glass
- Operating Temp. Range 0 Degrees to 150 Degrees F
- Characteristics Glycerin Filled Seal
- Calibration Certificate Included No
- Series 1259 with 312SS seal
- Includes 316 Stainless Steal Seal with Flushing Connection
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: 451259SD04L50312SS04TXCG600
- MPN: 451259SD04L/50312SS04TXCG600#
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: BR
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Dial Pressure Gauges with Diaphragm Seal
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
