K4696 Pressure Transmitter 0 to 300 psi 1/8 in MPN:G17M0142CD300#
The K4696 pressure transmitter serves various industries such as hydraulics, pneumatics, and chemical processing where accurate monitoring of pressure levels is crucial. It provides excellent precision even in harsh environments due to its stainless-steel construction that withstands corrosion and wear. Its compatibility with most data acquisition systems makes it a valuable tool for collecting real-time critical data efficiently, allowing users to analyze and monitor pressure levels with ease while delivering consistent results each time. Additionally, the 1/8 inch NPT connection enables easy installation into existing equipment without disrupting operations or requiring additional changes, ensuring minimal downtime and maximized productivity. The versatility of this device makes it an ideal choice for various applications, from manufacturing to aerospace, where precise pressure measurement is essential, delivering reliable and consistent performance over time.
Technical Specifications
- Transmitter Type Pressure Transmitter
- Wetted Materials - Transmitters Stainless Steel
- Range Values - Transmitter 0 to 300
- Range Units - Transmitter psi
- Accuracy - Transmitter +/-0.50% Full Scale
- Electrical Connections - Transmitter 4 Pin Hirschmann Style A DIN 43650-A Connector
- Power Required - Transmitters 9 to 36V DC
- Process Connection Size - Transmitter 1/8 in
- Process Connection Type - Transmitter MNPT
- Output - Transmitter 4 to 20mA DC
- Operating Temp. - Transmitter -40 Degrees to 257 Degrees F
- Wiring Entry - Transmitter 1/2 in FNPT
- Housing 304 Stainless Steel
- Loop Resistance Dependent on Loop Supply Voltage
- Max. Pressure (PSI) 600 psi
- Thermal Error +/-3% (-4 Degrees to 185 Degrees F)
- Compatible With Any Process Compatible with 316 Stainless Steel
- Includes Instructions
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: G17M0142CD300
- MPN: G17M0142CD300#
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Standard Pressure and Vacuum Transmitters
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112107
- UNSPSC Class ID: 21
- UNSPSC Commodity Name: Transducers
- UNSPSC Commodity ID: 07
- UNSPSC Commodity Name: Electro pneumatic transducers
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
