K4698 Pressure Transmitter 0 to 200 psi 1/4 in MPN:G17M0242CD200#
SKU
226-CXG-5DEA8
K4698 Pressure Transmitter 0 to 200 psi 1/4 in
Introducing our high-precision Pressure Transmitter for the accurate measurement of liquids and gases! Ideal for a wide range of industries such as automotive, pharmaceutical, and chemical manufacturing, this compact transmitter boasts thin film technology that reduces noise levels and improves temperature coefficient accuracy. With compatibility with most fluid types, you can easily mount it in tight spaces without worrying about interference or malfunction. Elevate your performance and reliability standards with our Ashcroft Pressure Transmitter 0 to 200 psi 1/4 in. Experience the precision advantage today!
Top product features:
- Thin film technology to reduce noise levels and temperature coefficients
- Compatibility with most fluid types
- Can be mounted in confined spaces.
Top product applications:
- Measuring pressure in automotive systems, such as fuel, oil, and air pressure
- Monitoring pressure levels in hydraulic systems in manufacturing plants and construction sites
- Testing and calibrating equipment in research labs and quality control departments
This compact transmitter features thin film technology that helps reduce noise levels and temperature coefficients. It also helps to achieve a high level of accuracy. Compatible with most types of fluids. Can be mounted in confined spaces.
Technical Specifications
- Transmitter Type Pressure Transmitter
- Wetted Materials - Transmitters Stainless Steel
- Range Values - Transmitter 0 to 200
- Range Units - Transmitter psi
- Accuracy - Transmitter +/-0.50% Full Scale
- Electrical Connections - Transmitter 4 Pin Hirschmann Style A DIN 43650-A Connector
- Power Required - Transmitters 9 to 36V DC
- Process Connection Size - Transmitter 1/4 in
- Process Connection Type - Transmitter MNPT
- Output - Transmitter 4 to 20mA DC
- Operating Temp. - Transmitter -40 Degrees to 257 Degrees F
- Wiring Entry - Transmitter 1/2 in FNPT
- Housing 304 Stainless Steel
- Loop Resistance Dependent on Loop Supply Voltage
- Max. Pressure (PSI) 400 psi
- Thermal Error +/-3% (-4 Degrees to 185 Degrees F)
- Compatible With Any Process Compatible with 316 Stainless Steel
- Includes Instructions
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: G17M0242CD200
- MPN: G17M0242CD200#
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026204000
- GDS Category Name: Standard Pressure and Vacuum Transmitters
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112107
- UNSPSC Class ID: 21
- UNSPSC Commodity Name: Transducers
- UNSPSC Commodity ID: 07
- UNSPSC Commodity Name: Electro pneumatic transducers
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 4, 2024 7:47am UTC
