K4698 Pressure Transmitter 0 to 60 psi 1/4 in MPN:G17M0242CD60#
Free Shipping
In Stock
The K4698 Pressure Transmitter offers superior accuracy within its specified range of 0-60psi with +/-2% of full scale while maintaining compact size; making it a versatile tool suited for industrial applications such as manufacturing, automotive or aviation sectors monitoring hydraulic/pneumatic systems. Its robust design enhances durability when exposed to rough conditions that could otherwise compromise its performance. Investing in this pressure transmitter ensures predictive maintenance strategies enabling operators identify potential risks before breakdowns occur; preventing costly repairs or production downtime hence saving time and resources on operations. Furthermore, the K4698 is ideal for applications that necessitate continuous surveillance, ensuring critical pressure readings are accessible even in tight spaces due to its compact design allowing quick response when need arises resulting in an overall cost-effective investment benefitting numerous sectors within various fields of operation.
Technical Specifications
- Transmitter Type Pressure Transmitter
- Wetted Materials - Transmitters Stainless Steel
- Range Values - Transmitter 0 to 60
- Range Units - Transmitter psi
- Accuracy - Transmitter +/-0.50% Full Scale
- Electrical Connections - Transmitter 4 Pin Hirschmann Style A DIN 43650-A Connector
- Power Required - Transmitters 9 to 36V DC
- Process Connection Size - Transmitter 1/4 in
- Process Connection Type - Transmitter MNPT
- Output - Transmitter 4 to 20mA DC
- Operating Temp. - Transmitter -40 Degrees to 257 Degrees F
- Wiring Entry - Transmitter 1/2 in FNPT
- Housing 304 Stainless Steel
- Loop Resistance Dependent on Loop Supply Voltage
- Max. Pressure (PSI) 120 psi
- Thermal Error +/-3% (-4 Degrees to 185 Degrees F)
- Compatible With Any Process Compatible with 316 Stainless Steel
- Includes Instructions
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: G17M0242CD60
- MPN: G17M0242CD60#
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026204000
- GDS Category Name: Standard Pressure and Vacuum Transmitters
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112107
- UNSPSC Class ID: 21
- UNSPSC Commodity Name: Transducers
- UNSPSC Commodity ID: 07
- UNSPSC Commodity Name: Electro pneumatic transducers
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
