K4698 Pressure Transmitter 0 to 5000 psi 1/4 MPN:G17M0242DO5000#
The K4698 Pressure Transmitter from Ashcroft is an ideal choice for any application requiring high accuracy and precise measurements of pressure in confined spaces. This compact, thin-film transmitter utilizes advanced technology to deliver exceptional performance while maintaining high resistance to noise levels and temperature fluctuations. Suitable for most fluids, the K4698 provides excellent accuracy with +/-0.5% full scale and can measure up to 5000 psi. Its stainless-steel construction ensures durability and long-lasting performance even in demanding environments. Whether you're working in the chemical industry, manufacturing, or any other application requiring pressure measurements, the K4698 Pressure Transmitter from Ashcroft has you covered!
Top product features:
- Compact and thin film technology
- High accuracy
- Stainless steel construction
Top product applications:
- Industrial equipment monitoring
- Process control systems
- Fluid level measurement
Technical Specifications
- Transmitter Type Pressure Transmitter
- Wetted Materials - Transmitters Stainless Steel
- Range Values - Transmitter 0 to 5000
- Range Units - Transmitter psi
- Accuracy - Transmitter +/-0.50% Full Scale
- Electrical Connections - Transmitter 4 Pin Hirschmann Style A DIN 43650-A Connector
- Power Required - Transmitters 9 to 36V DC
- Process Connection Size - Transmitter 1/4 in
- Process Connection Type - Transmitter MNPT
- Output - Transmitter 4 to 20mA DC
- Operating Temp. - Transmitter -40 Degrees to 257 Degrees F
- Wiring Entry - Transmitter 1/2 in FNPT
- Housing 304 Stainless Steel
- Loop Resistance Dependent on Loop Supply Voltage
- Max. Pressure (PSI) 7,500 psi
- Thermal Error +/-3% (-4 Degrees to 185 Degrees F)
- Compatible With Any Process Compatible with 316 Stainless Steel
- Includes Instructions
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: G17M0242DO5000
- MPN: G17M0242DO5000#
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026204000
- GDS Category Name: Standard Pressure and Vacuum Transmitters
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112107
- UNSPSC Class ID: 21
- UNSPSC Commodity Name: Transducers
- UNSPSC Commodity ID: 07
- UNSPSC Commodity Name: Electro pneumatic transducers
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
