K4698 Pressure Transmitter 0 to 60 psi 1/4 in MPN:G17M0242DO60#
The K4698 is an accurate pressure transmitter designed for industrial environments with a range of 0 to 60 psi. Made up of rugged materials ensuring endurance against challenging situations; this device boasts +/-1% full scale accuracy, providing critical readings crucial to preventative maintenance programs while ensuring precise measurements when time matters most. Compact in size yet robust in performance; this device provides real-time insight into critical pressure levels enabling swift response, ultimately preventing expensive downtime and disruption associated with unplanned system malfunctions. In summary, the K4698 Pressure Transmitter is ideal for industries dealing in hydraulics/pneumatics requiring continuous monitoring on key performance indicators as well as organizations focusing on cost effective investments targeting high ROI levels derived from advanced preventative maintenance procedures across diverse verticals ranging from Manufacturing to Aerospace among others.
Technical Specifications
- Transmitter Type Pressure Transmitter
- Wetted Materials - Transmitters Stainless Steel
- Range Values - Transmitter 0 to 60
- Range Units - Transmitter psi
- Accuracy - Transmitter +/-0.50% Full Scale
- Electrical Connections - Transmitter 4 Pin Hirschmann Style A DIN 43650-A Connector
- Power Required - Transmitters 9 to 36V DC
- Process Connection Size - Transmitter 1/4 in
- Process Connection Type - Transmitter MNPT
- Output - Transmitter 4 to 20mA DC
- Operating Temp. - Transmitter -40 Degrees to 257 Degrees F
- Wiring Entry - Transmitter 1/2 in FNPT
- Housing 304 Stainless Steel
- Loop Resistance Dependent on Loop Supply Voltage
- Max. Pressure (PSI) 120 psi
- Thermal Error +/-3% (-4 Degrees to 185 Degrees F)
- Compatible With Any Process Compatible with 316 Stainless Steel
- Includes Instructions
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: G17M0242DO60
- MPN: G17M0242DO60#
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026204000
- GDS Category Name: Standard Pressure and Vacuum Transmitters
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112107
- UNSPSC Class ID: 21
- UNSPSC Commodity Name: Transducers
- UNSPSC Commodity ID: 07
- UNSPSC Commodity Name: Electro pneumatic transducers
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
