K4243 Pressure Gauge 2-1/2 Dial Size Blk Case MPN:DG2531L0NAM02L3000#-XCYLM
K4243 Pressure Gauge is a versatile precision tool widely used across different industries for measuring pressure levels with its +/- 1% accuracy, large 2.5-inch dial size and temperatures ranging from -100F to +600F making it ideal for chemical plants, HVAC systems, laboratories and various others. Its sturdy black casing adds safety, while the cost-effective price makes this gauge a perfect solution for any user demanding precise pressure measurements without sacrificing reliability or performance in their application. The durable construction ensures consistency over time withstanding daily wear & tear while its accurate readings guarantee high-performance industrial-grade results each time you use it. With various applications across diverse sectors, K4243 Pressure Gauge is an indispensable addition to the toolbox of professional technicians, maintenance teams or engineers.
Technical Specifications
- Digital Pressure and Vacuum Gauge Type Digital Pressure Gauge
- Item Digital Pressure Gauge
- Gauge Nominal Dial Size 2 1/2 in
- Basic Gauge Case Material Plastic
- Basic Gauge Wetted Parts Stainless Steel
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 3000
- Digital Gauge Accuracy +/-0.50% Full Scale
- Display LCD
- Number of Display Digits 5
- Socket Material Stainless Steel
- Case Material ABS Polycarbonate
- Case Color Black
- Digital Gauge Display Units bar, ft wc, in Hg, in wc, kg/sq cm, kPa, mbar, mm Hg, MPa, psi
- Memory Storage min/max
- Resolution Dependent on Range
- Powered By (2) AA Batteries
- Agency Compliance CE, CRN, UL
- Gauge Operating Temp. Range -4 Degrees to 140 Degrees F
- Features Bar Graph Battery Display
- Series 0.50% Accuracy Digital Gauge
- Calibration Certificate No
- Peak Hold Yes
- Includes Alkaline Batteries
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: DG2531L0NAM02L3000XCYLM
- MPN: DG2531L0NAM02L3000#-XCYLM
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026204000
- GDS Category Name: Industrial Process and Test Digital Pressure Gau
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
