D0811 Pressure Gauge 0 to 30 psi 6In 1/4In NPT MPN:601082AS02L30C4
The sturdy steel construction of this pressure gauge makes it durable and reliable ensuring consistent accurate readings across diverse applications requiring monitoring or testing at low pressure ranges up to 30psi which covers air, hydraulic, pneumatic, industrial processes. Its compact size featuring a 6-inch dial offers enhanced maneuverability when installing within tight spaces while its 1/4-inch NPT connection allows seamless integration into any machinery or system providing accurate and immediate insight on system performance without disrupting operations via user-friendly intuitive readings. This cost-effective gauge includes both vacuum and pressure scale markings making it suitable for multiple applications across diverse industries such as HVAC, laboratories, manufacturing plants where precision is key eliminating the need for additional tools or accessories thus ensuring efficiency at all times.
Technical Specifications
- Item Pressure Gauge
- Gauge Application Test
- Gauge Nominal Dial Size 6 in
- Basic Gauge Case Material Aluminum
- Basic Gauge Wetted Parts Brass / Bronze
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 30
- Gauge Accuracy +/-0.25%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 0.1
- Gauge Case Material Aluminum
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass
- Basic Gauge Sensor Material Bronze
- Gauge Sensor Material Bronze
- Gauge Lens Material Glass
- Basic Gauge Lens Material Glass
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Calibration Certificate Included Yes, NIST with Data
- Series 1082
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: 601082AS02L30C4
- MPN: 601082AS02L30C4
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Dial Test Pressure Gauges
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112406
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Vacuum gauges
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
