D0813 Pressure Gauge 0 to 10000 psi 4-1/2In MPN:451082PS02L10MC4
SKU
226-CXG-2RFD5
D0813 Pressure Gauge 0 to 10000 psi 4-1/2In
Ashcroft D0813 Pressure Gauge is an exceptional tool for measuring pressure levels in demanding industrial environments. It comes with an aluminum case that provides protection against corrosion and impact while ensuring durability. The gauge features a 4-1/2 nominal dial size, making it easy to read measurements accurately. This versatile instrument boasts Monel wetted parts which resist corrosion from a wide range of fluids, including chemicals and salts. Its compact design allows for mounting in tight spaces while maintaining precise pressure reading capabilities. The Ashcroft D0813 Pressure Gauge is ideal for test applications requiring reliable performance and accuracy within an extensive pressure range of 0-10,000 psi.
Top product features:
- Corrosion resistant aluminum case
- Monel wetted parts for fluid resistance
- Test application gauge
Top product applications:
- Test and measurement for industrial processes
- Monitoring pressure levels in HVAC systems
- Calibration of other pressure devices
This gauge features aluminum case construction to resist corrosion and impact in demanding applications.
Technical Specifications
- Item Pressure Gauge
- Gauge Application Test
- Gauge Nominal Dial Size 4 1/2 in
- Basic Gauge Case Material Aluminum
- Basic Gauge Wetted Parts Monel
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 10,000
- Gauge Accuracy +/-0.25%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 50
- Gauge Case Material Aluminum
- Gauge Primary Range Numbered Graduations 1000
- Gauge Case Color Black
- Basic Gauge Socket Material Monel
- Gauge Socket Material Monel 400
- Basic Gauge Sensor Material Monel
- Gauge Sensor Material Monel K
- Gauge Lens Material Glass
- Basic Gauge Lens Material Glass
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Calibration Certificate Included Yes, NIST with Data
- Series 1082
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: 451082PS02L10MC4
- MPN: 451082PS02L10MC4
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Dial Test Pressure Gauges
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112406
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Vacuum gauges
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
