D0805 Pressure Gauge 0 to 100 psi 4-1/2In MPN:451082AS02L100 C4
Free Shipping
In Stock
Our premium quality pressure gauge is ideal for anyone in search of precision measurement tools within various industries including chemical, engineering or laboratory use while having the capability of measuring up to a maximum of 100 psi thus promoting top-notch accuracy. Featuring a rangeable pressure dial hence making it easy to read at once with a direct reading from zero up to the max psi indicator thus catering for various settings, this high-quality pressure gauge is made with a stainless steel wetted material ensuring durability and long-lasting use. The compact design and lightweight nature of this pressure gauge make it portable hence promoting versatility while also being compatible with numerous equipment types thus making it an essential item within any industrial setting or laboratory, promoting consistent and reliable readings at all times while fulfilling every customer's expectations.
Technical Specifications
- Item Pressure Gauge
- Gauge Application Test
- Gauge Nominal Dial Size 4 1/2 in
- Basic Gauge Case Material Aluminum
- Basic Gauge Wetted Parts Brass / Bronze
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 100
- Gauge Accuracy +/-0.25%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 0.5
- Gauge Case Material Aluminum
- Gauge Primary Range Numbered Graduations 10
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass
- Basic Gauge Sensor Material Bronze
- Gauge Sensor Material Phosphor Bronze
- Gauge Lens Material Glass
- Basic Gauge Lens Material Glass
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Calibration Certificate Included Yes, NIST with Data
- Series 1082
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: 451082AS02L100C4
- MPN: 451082AS02L100 C4
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Dial Test Pressure Gauges
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112406
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Vacuum gauges
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
