D0801 Vacuum Gauge 30 Hg to 0 3In 1/4In NPT MPN:301084S02LVACC4
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-cxg-2rfc5
D0801 Vacuum Gauge 30 Hg to 0 3In 1/4In NPT
The D0801 Vacuum Gauge 30 Hg to 0 3In 1/4In NPT is a precise measurement tool that accurately reads vacuum pressure within the specified range, making it perfect for applications in scientific research and industrial processes where precision is key.
This gauge features stainless steel case construction to resist corrosion and impact in demanding applications.
Technical Specifications
- Item Vacuum Gauge
- Gauge Application Test
- Gauge Nominal Dial Size 3 in
- Basic Gauge Case Material Stainless Steel
- Basic Gauge Wetted Parts Stainless Steel
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units in Hg
- Gauge Primary Range Values -30 to 0
- Gauge Accuracy +/-0.50%
- Pressure and Vacuum Gauge Type Vacuum Gauge
- Gauge Panel Mountable No
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 0.5
- Gauge Case Material 316 Stainless Steel
- Gauge Case Color Stainless Steel
- Basic Gauge Socket Material Stainless Steel
- Gauge Socket Material 316 Stainless Steel
- Basic Gauge Sensor Material Stainless Steel
- Gauge Sensor Material 316 Stainless Steel
- Gauge Lens Material Glass
- Basic Gauge Lens Material Glass
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Calibration Certificate Included Yes, NIST with Data
- Series 1084
- Includes Nylon Carrying Pouch
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: 301084S02LVACC4
- MPN: 301084S02LVACC4
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Dial Test Pressure Gauges
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112406
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Vacuum gauges
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 3, 2024 8:28pm UTC
Category: Pressure and Vacuum Measuring
