D0801 Pressure Gauge 0 to 300 psi 3In 1/4In MPN:301084S02L300C4
Free Shipping
In Stock
Take your manufacturing capabilities to the next level with our Combination Drill & Thread Mills, Thread Size: #10-24, Finish Coating: Titanium Diboride specifically engineered for precision thread forming tasks demanding unparalleled wear resistance and heat/corrosion protection during tough machining operations on hard materials such as steel, brass or aluminum. This powerful tool boasts a Titanium Diboride finish coating that provides a smooth surface finish to reduce friction, prevent chip clogging and increase precision while maintaining its strength, making it the ideal choice for aerospace, automotive and other high-stress industries seeking maximum productivity without compromise on quality. Upgrade your production process today with Combination Drill & Thread Mills, Thread Size: #10-24, Finish Coating: Titanium Diboride!
Technical Specifications
- Item Pressure Gauge
- Gauge Application Test
- Gauge Nominal Dial Size 3 in
- Basic Gauge Case Material Stainless Steel
- Basic Gauge Wetted Parts Stainless Steel
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 300
- Gauge Accuracy +/-0.50%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 2
- Gauge Case Material 316 Stainless Steel
- Gauge Case Color Stainless Steel
- Basic Gauge Socket Material Stainless Steel
- Gauge Socket Material 316 Stainless Steel
- Basic Gauge Sensor Material Stainless Steel
- Gauge Sensor Material 316 Stainless Steel
- Gauge Lens Material Glass
- Basic Gauge Lens Material Glass
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Calibration Certificate Included Yes, NIST with Data
- Series 1084
- Includes Nylon Carrying Pouch
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: 301084S02L300C4
- MPN: 301084S02L300C4
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Dial Test Pressure Gauges
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112406
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Vacuum gauges
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
