D0799 Vacuum Gauge 30 Hg to 0 3In 1/4In NPT MPN:30-1084S 02L VAC
Free Shipping
In Stock
The 30HG vacuum gauge with dial indicator has a pressure range from -30in Hg to 0 in Hg in gauge readings for precise and accurate measurement of vacuum or gas pressure within a variety of industrial settings like testing, research labs or manufacturing plants where sensitive instruments require exact readouts. Its sturdy construction from carbon steel with satin finish delivers long service life even when subjected to demanding conditions such as harsh chemicals or heat while its accuracy is guaranteed by being calibrated with the latest traceable standards certified by NIST (National Institute of Standards and Technology). Furthermore, its compact design enables easy portability from location to location whether at shop floors, warehouses or testing rooms. With its versatility and durability, this vacuum gauge meets various needs without adding extra cost on replacement making it a top choice for users seeking value without compromising quality in pressure measurement applications.
Technical Specifications
- Item Vacuum Gauge
- Gauge Application Test
- Gauge Nominal Dial Size 3 in
- Basic Gauge Case Material Stainless Steel
- Basic Gauge Wetted Parts Stainless Steel
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units in Hg
- Gauge Primary Range Values -30 to 0
- Gauge Accuracy +/-0.50%
- Pressure and Vacuum Gauge Type Vacuum Gauge
- Gauge Panel Mountable No
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 0.2
- Gauge Case Material 316 Stainless Steel
- Gauge Case Color Stainless Steel
- Basic Gauge Socket Material Stainless Steel
- Gauge Socket Material 316 Stainless Steel
- Basic Gauge Sensor Material Stainless Steel
- Gauge Sensor Material 316 Stainless Steel
- Gauge Lens Material Glass
- Basic Gauge Lens Material Glass
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Calibration Certificate Included No
- Series 1084S
- Includes Nylon Carrying Pouch
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: 301084S02LVAC
- MPN: 30-1084S 02L VAC
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Dial Test Pressure Gauges
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 3, 2024 8:25pm UTC Category: Pressure and Vacuum Measuring
