Ball Check Valve PVC 1-1/2 Socket MPN:1213015
Ball Check Valve PVC 1-1/2 Socket
Ball Check Valve PVC 1-1/2 Socket is an excellent addition to any plumbing system, allowing free flow in one direction while preventing backflow; the brass construction provides durability under demanding conditions while its sizeable socket ensures simple installation. Ideal for various applications including HVAC systems or water treatment facilities, this valve prevents costly damage to equipment and pipelines while safeguarding clean fluids from contamination.
Get Asahi item #1213015 from our selection of Plumbing Valves while supporting Veterans 🎖.
Technical Specifications
- Item - Check Valves Check Valve
- Flow Design Single
- Mechanism and Body Design Inline Ball
- Body Material - Valves PVC
- Pipe or Tube Size 1 1/2 in
- Connection Type Socket x Socket
- Cracking Pressure 1.0 psi
- Mounting Orientation Horizontal, Vertical
- Seal Material FKM
- Max. Temp. - Valves 120 Degrees F
- Min. Temp. - Valves 30 Degrees F
- Max. Water Pressure - Valves 150 psi @ 120 Degrees F
- Max. Steam Pressure - Valves Not Rated
- Seat Material FKM
- Full Flow - Valves No
- Application - Valves General Purpose
- Length 5 15/16 in
- Overall Height 3 25/32 in
- Standards ASTM D1784 Cell Class 12454A, NSF-61
Manufacturer Details
- Manufacturer: Asahi
- Condensed Mfg Number: 1213015
- MPN: 1213015
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: JP
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Check Valves
- GDS Family Name: Check Valves and Backflow Preventers
- GDS Segment Name: Plumbing
- UNSPSC: 40141618
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Valves
- UNSPSC Commodity ID: 18
- UNSPSC Commodity Name: Ball check valves
- UNSPSC Family ID: 14
- UNSPSC Family Name: Fluid and gas distribution
- UNSPSC Segment ID: 40
- UNSPSC Segment Name: Distribution and Conditioning Systems and Equipment and Components
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on November 17, 2023 12:17pm UTC
Category: Check Valves and Backflow Preventers
