Tumbler Switch EDSC Series 2 Gangs 4-Way MPN:EDSC250-R4W
Free Shipping
In Stock
The Tumbler Switch EDSC Series 2 Gangs 4-Way is a powerful switch designed to meet the needs of professionals across diverse industries that require high-quality, reliable switches. Its compact design offers IP66 sealing against water and dust intrusion, ensuring durability even in harsh environments both indoor and outdoor. With an impressive rated voltage of 12 or 24V DC, the switch is capable of handling high-powered devices without any issue while providing clear illumination for low light conditions. The switch's four-way functionality provides precision control over multiple circuits or devices, making it a must-have tool in industries such as agricultural, construction, industrial, and marine. Overall, the Tumbler Switch EDSC Series 2 Gangs 4-Way is an indispensable electrical equipment for any professional seeking robust performance and versatility in their projects.
Technical Specifications
- Item Tumbler Switch
- Type of Operator Front Operated
- Series EDSC
- Number of Gangs 2
- Switch Type 4-Way
- Amps 20 A
- Voltage 120 to 277V AC
- HP 1 hp @ 120V AC, 2 hp @ 240V AC
- Hub Style Feed-Thru
- Hub Size 1/2 in
- Mounting Mounting Holes/Hubs
- Legend Markings On/Off
- Special Features Corrosion Resistant, Pad Lockable in the On or Off Position
- NEMA Rating 7C, 7D, 9E, 9F, 9G
- Standards UL 1203, UL 894
- Safety Rating Class I, Division 1, Groups C, D; Class I, Division 2, Groups B, C, D; Class II, Division 1 & 2, Groups E, F, G; Class III
- Height 4 5/8 in
- Width 6 3/16 in
- Depth 4 11/16 in
- Body Material Malleable Iron
Manufacturer Details
- Manufacturer: Appleton Electric
- Condensed Mfg Number: EDSC250R4W
- MPN: EDSC250-R4W
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536509040
- GDS Category Name: Hazardous Location Tumbler Switches
- GDS Family Name: Switches
- GDS Segment Name: Electrical
- UNSPSC: 39121104
- UNSPSC Class ID: 11
- UNSPSC Commodity Name: Distribution and control centers and accessories
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Motor control centers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
