Tumbler Switch EDSC Series 2 Gang 2-Pole MPN:EDSC250-R2
Free Shipping
In Stock
Introducing the Tumbler Switch EDSC Series 2 Gang 2-Pole from Appleton Electric - the perfect solution for safe and reliable electrical connections in hazardous locations. This high-quality switch is designed to prevent arcing during connect and disconnect operations of lighting and power loads, making it ideal for use in chemical plants, refineries, and other process industries. With its front-operated design, EDSC series classification, two gang capability, and two-pole switch type, this product is a versatile and durable choice that offers many benefits to its users. Whether you need to control lighting, power, or other electrical systems in hazardous areas, the Tumbler Switch EDSC Series 2 Gang 2-Pole from Appleton Electric has you covered. Don't take chances with your safety - choose this reliable switch today!
Top product features:
- Front-operated design for easy use in hazardous areas
- Suitable for installation in chemical plants, refineries, and other process industries
- Two gang capability for controlling multiple devices with one switch
Top product applications:
- Lighting control in hazardous areas like chemical plants and refineries
- Power control for machines or equipment in classified locations
- Controlling two devices with one switch in dangerous environments
Technical Specifications
- Item Tumbler Switch
- Type of Operator Front Operated
- Series EDSC
- Number of Gangs 2
- Switch Type 2-Pole
- Amps 20 A
- Voltage 120 to 277V AC
- HP 1 hp @ 120V AC, 2 hp @ 240V AC
- Hub Style Feed-Thru
- Hub Size 1/2 in
- Mounting Mounting Holes/Hubs
- Legend Markings On/Off
- Special Features Corrosion Resistant, Pad Lockable in the On or Off Position
- NEMA Rating 7C, 7D, 9E, 9F, 9G
- Standards UL 1203, UL 894
- Safety Rating Class I, Division 1, Groups C, D; Class I, Division 2, Groups B, C, D; Class II, Division 1 & 2, Groups E, F, G; Class III
- Height 4 5/8 in
- Width 6 3/16 in
- Depth 4 11/16 in
- Body Material Malleable Iron
Manufacturer Details
- Manufacturer: Appleton Electric
- Condensed Mfg Number: EDSC250R2
- MPN: EDSC250-R2
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536509035
- GDS Category Name: Hazardous Location Tumbler Switches
- GDS Family Name: Switches
- GDS Segment Name: Electrical
- UNSPSC: 39121104
- UNSPSC Class ID: 11
- UNSPSC Commodity Name: Distribution and control centers and accessories
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Motor control centers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 4, 2024 12:32pm UTC Category: Switches
