Tumbler Switch EDSC Series 2 Gang 1-Pole MPN:EDSC210-R1
Free Shipping
In Stock
Introducing the Tumbler Switch EDSC Series 2 Gang 1-Pole from Appleton Electric - designed for superior safety and performance in hazardous environments. Ideal for installation in chemical plants, refineries, and other process industries, this tumbler switch helps prevent arcing during connect and disconnect operations of lighting and power loads. With a front operated design, it ensures easy access and use while its durable construction guarantees long-lasting performance. The EDSC Series also offers an extensive range of applications, making it the perfect choice for any hazardous area where ignitable vapors, gases, or combustible dusts are present. Invest in safety and reliability with the Tumbler Switch EDSC Series 2 Gang 1-Pole from Appleton Electric today!
Top product features:
- Arcing prevention technology
- Front operated design for easy access and use
- Durable construction for long-lasting performance
Top product applications:
- Hazardous area lighting and power control in chemical plants and refineries
- Use in environments with ignitable vapors, gases, or combustible dusts
- Two gang control of lights or devices in explosive atmospheres
Technical Specifications
- Item Tumbler Switch
- Type of Operator Front Operated
- Series EDSC
- Number of Gangs 2
- Switch Type 1-Pole
- Amps 20 A
- Voltage 120 to 277V AC
- HP 1 hp @ 120V AC, 2 hp @ 240V AC
- Hub Style Feed-Thru
- Hub Size 1 in
- Mounting Mounting Holes/Hubs
- Legend Markings On/Off
- Special Features Corrosion Resistant, Pad Lockable in the On or Off Position
- NEMA Rating 7C, 7D, 9E, 9F, 9G
- Standards UL 1203, UL 894
- Safety Rating Class I, Division 1, Groups C, D; Class I, Division 2, Groups B, C, D; Class II, Division 1 & 2, Groups E, F, G; Class III
- Height 4 5/8 in
- Width 6 3/16 in
- Depth 4 11/16 in
- Body Material Malleable Iron
Manufacturer Details
- Manufacturer: Appleton Electric
- Condensed Mfg Number: EDSC210R1
- MPN: EDSC210-R1
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536509035
- GDS Category Name: Hazardous Location Tumbler Switches
- GDS Family Name: Switches
- GDS Segment Name: Electrical
- UNSPSC: 39121104
- UNSPSC Class ID: 11
- UNSPSC Commodity Name: Distribution and control centers and accessories
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Motor control centers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
