Tumbler Switch EDSC Series 1 Gang 2-Pole MPN:EDSC150-R2
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-cxg-13v062
Tumbler Switch EDSC Series 1 Gang 2-Pole
Introducing our Tumbler Switch EDSC Series, the perfect solution for controlling lighting and power loads in hazardous environments. With a front-operated design and 1-gang, 2-pole switch type, this tumbler switch is specifically engineered to prevent arcing during connect and disconnect operation, making it ideal for use in chemical plants, refineries, and other process industries where ignitable vapors, gases, or combustible dusts are present. Its durable construction and reliable performance make it the go-to choice for industrial settings that require safe, efficient, and dependable switching solutions. Upgrade your lighting and power controls today with our Tumbler Switch EDSC Series!
Top product features:
- Prevents arcing during connect and disconnect operation
- Suitable for use in hazardous environments
- Durable construction and reliable performance
Top product applications:
- Use in chemical plants, refineries, and other process industries where ignitable vapors, gases, and combustible dusts are present.
- Use as a switch to control lighting and power loads.
- Installation in hazardous areas with classified environments.
This tumbler switch is designed to help prevent arcing during connect and disconnect operation of lighting and light power loads. It is suitable for installation in chemical plants, refineries, and other process industries. Use in classified areas where ignitable vapors, gases, and combustible dusts are present.
Technical Specifications
- Item Tumbler Switch
- Type of Operator Front Operated
- Series EDSC
- Number of Gangs 1
- Switch Type 2-Pole
- Amps 20 A
- Voltage 120 to 277V AC
- HP 1 hp @ 120V AC, 2 hp @ 240V AC
- Hub Style Feed-Thru
- Hub Size 1/2 in
- Mounting Mounting Holes/Hubs
- Legend Markings On/Off
- Special Features Corrosion Resistant, Pad Lockable in the On or Off Position
- NEMA Rating 7C, 7D, 9E, 9F, 9G
- Standards UL 1203, UL 894
- Safety Rating Class I, Division 1, Groups B, C, D; Class I, Division 2, Groups B, C, D; Class II, Division 1 & 2, Groups E, F, G; Class III
- Height 4 5/8 in
- Width 3 in
- Depth 4 11/16 in
- Body Material Malleable Iron
Manufacturer Details
- Manufacturer: Appleton Electric
- Condensed Mfg Number: EDSC150R2
- MPN: EDSC150-R2
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536509035
- GDS Category Name: Hazardous Location Tumbler Switches
- GDS Family Name: Switches
- GDS Segment Name: Electrical
- UNSPSC: 39121104
- UNSPSC Class ID: 11
- UNSPSC Commodity Name: Distribution and control centers and accessories
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Motor control centers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 4, 2024 12:32pm UTC
Category: Switches
