Tumbler Switch EDSC Series 1 Gang 4-Way MPN:EDSC110-R4W
Free Shipping
In Stock
Tumbler Switch EDSC Series is ideal for harsh environments where ignitable gas/dust mixtures may be present such as Class I Division I locations and Zone 1 or 2 hazardous locations in petrochemical plants, refineries or other industries involving flammable substances. Its rugged construction from stainless steel or polyamide ensures durability while meeting hazardous location certifications such as FM/UL, CSA, ATEX or IECEx making it suitable for applications requiring safe electrical switching solutions in demanding conditions where ignitable substances are present, thus ensuring worker safety is a top priority. The device's versatility and ability to operate on AC or DC voltage withstand high temperature and pressure makes it ideal for controlling electrical loads on machinery used within these industries, minimizing the risk of accidents due to equipment failure from power surges or spikes, while maximizing productivity and reducing downtime.
Technical Specifications
- Item Tumbler Switch
- Type of Operator Front Operated
- Series EDSC
- Number of Gangs 1
- Switch Type 4-Way
- Amps 20 A
- Voltage 120 to 277V AC
- HP 1 hp @ 120V AC, 2 hp @ 240V AC
- Hub Style Feed-Thru
- Hub Size 1 in
- Mounting Mounting Holes/Hubs
- Legend Markings On/Off
- Special Features Corrosion Resistant, Pad Lockable in the On or Off Position
- NEMA Rating 7C, 7D, 9E, 9F, 9G
- Standards UL 1203, UL 894
- Safety Rating Class I, Division 1, Groups C, D; Class I, Division 2, Groups B, C, D; Class II, Division 1 & 2, Groups E, F, G; Class III
- Height 4 5/8 in
- Width 3 in
- Depth 4 11/16 in
- Body Material Malleable Iron
Manufacturer Details
- Manufacturer: Appleton Electric
- Condensed Mfg Number: EDSC110R4W
- MPN: EDSC110-R4W
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536509040
- GDS Category Name: Hazardous Location Tumbler Switches
- GDS Family Name: Switches
- GDS Segment Name: Electrical
- UNSPSC: 39121104
- UNSPSC Class ID: 11
- UNSPSC Commodity Name: Distribution and control centers and accessories
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Motor control centers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
