Manual Motor Starter Dead-End Hub 1 2P MPN:EDS31102
Free Shipping
In Stock
The manual motor starter dead-end hub type 1-2P is specifically designed for controlling and protecting single or three-phase motors in numerous industries such as food processing plants, oil & gas refineries, water treatment facilities, HVAC systems or mining operations amongst others. With its compact construction, the starter offers high performance starting capabilities up to 7.5HP / 6kW and offers maximum motor protection through its built-in thermal overload protection which automatically disconnects the power supply in case of an overcurrent situation or motor jams due to any reason. Its straightforward design reduces installation time, and its ease of use is vital when dealing with emergency shutdown scenarios where quick and safe operations are crucial. Furthermore, the manual motor starter dead-end hub ensures reliable motor control via spring loaded pressure contacts, sealing mechanisms against dust, water or oil penetration hence providing low maintenance in harsh environment applications while enhancing productive uptime for companies requiring robust and reliable motor control systems.
Technical Specifications
- Item Motor Starter
- Amps AC 20 A
- Enclosure NEMA Rating 3, 7CD, 9EFG
- Hub Style Dead-End
- Hub Size 1 in
- Number of Gangs 1
- Description/Special Features Cast In Hubs. Interchangeable Heater Units.
- No. of Thermal Units Required 1
- Number of Poles 2
- Starter Type Manual
- Height 7.03 in
- Width 3.72 in
- Depth 5.31 in
- HP @ 120V 1 hp
- HP @ 240V 1 hp
- HP @ 32VDC 1/4 hp
- HP @ 120VDC 1 hp
- HP @ 240VDC 1 hp
- HP @ 115VDC 1 hp
- HP @ 230VDC 1 hp
- Standards UL508, UL 698, UL 1203, C22.2 No. 14-M, C22.2 No. 25, C22.2 No. 30, UL Listed for Class I, Division 1 and 2, Groups C, D; Class II, Groups E, F, G; and Class III
Manufacturer Details
- Manufacturer: Appleton Electric
- Condensed Mfg Number: EDS31102
- MPN: EDS31102
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536504000
- GDS Category Name: Hazardous Location Manual Motor Switches and Start
- GDS Family Name: Starters and Contactors
- GDS Segment Name: Electrical
- UNSPSC: 39121521
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Switches and controls and relays and accessories
- UNSPSC Commodity ID: 21
- UNSPSC Commodity Name: Motor starter controls
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
