Manual Motor Starter Dead-End Hub 1/2 1P MPN:EDS11101
Free Shipping
In Stock
An ideal component for various applications where motor control is needed, Anvil's manual motor starter dead-end hub offers superior functionality and durability at an affordable price. This single pole, 3/4 horsepower rated unit features a compact design, easy wiring options, and provides overload protection. It also features spring return mechanism for simplicity of operation and a NEMA size 14 mounting footprint that allows for compatibility with various devices on the market today. With its rugged construction, reliability, and efficiency, this motor starter hub offers superior performance in your industrial environment, making it an excellent choice for businesses of all types. Invest in dependable motor control today by choosing Anvil's manual motor starter dead-end hub.
Technical Specifications
- Item Motor Starter
- Amps AC 20 A
- Enclosure NEMA Rating 3, 7CD, 9EFG
- Hub Style Dead-End
- Hub Size 1/2 in
- Number of Gangs 1
- Description/Special Features Cast In Hubs. Interchangeable Heater Units.
- No. of Thermal Units Required 1
- Number of Poles 1
- Starter Type Manual
- Height 7.03 in
- Width 3.72 in
- Depth 5.31 in
- HP @ 120V 1 hp
- HP @ 240V 1 hp
- HP @ 32VDC 1/4 hp
- HP @ 240VDC 1/4 hp
- HP @ 230VDC 1/4 hp
- Standards UL508, UL 698, UL 1203, C22.2 No. 14-M, C22.2 No. 25, C22.2 No. 30, UL Listed for Class I, Division 1 and 2, Groups C, D; Class II, Groups E, F, G; and Class III
Manufacturer Details
- Manufacturer: Appleton Electric
- Condensed Mfg Number: EDS11101
- MPN: EDS11101
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536504000
- GDS Category Name: Hazardous Location Manual Motor Switches and Start
- GDS Family Name: Starters and Contactors
- GDS Segment Name: Electrical
- UNSPSC: 39121521
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Switches and controls and relays and accessories
- UNSPSC Commodity ID: 21
- UNSPSC Commodity Name: Motor starter controls
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
