Lug Union Steel 1 1/4 FNPT Class 3000 MPN:0361530801
The Indexable square-shoulder face mill R220.6902.502.24XO165A is designed to cater to industries requiring high precision and cutting accuracy for challenging operations like aerospace, medical or tool and die making sectors; These endmills offer indexable inserts made from tungsten carbide providing longer life span while maintaining stable dimensions and resistance against wear out due to their robust construction. Equipped with innovative coolant supply holes which promote heat dissipation during intense cutting processes, the customers gain value in increased productivity without compromising material quality resulting from excessive friction. This high-performance tool caters to professionals or machine shops needing exceptional versatility for diverse application scenarios within indexable square-shoulder endmills field.
Technical Specifications
- Item Threaded Union
- Pipe Fitting Material Black Forged Steel
- Fitting Schedule/Class Class 3000
- Pipe Size - Pipe Fitting 1-1/4 in
- Fitting Connection Type FNPT
- Standards ASME B16.11, ASTM A106, B1.20.1, MSS SP-83
- Max. Pressure 1500 psi @ 150 Degrees F
- Saturated Steam Pressure 300 psi @ 550 Degrees F
- Outside Dia. 3 23/64 in
- Number of Holes 2
- Hex Size 3 25/64 in
- Temp. Range -20 Degrees to 550 Degrees F
Manufacturer Details
- Manufacturer: Anvil
- Condensed Mfg Number: 0361530801
- MPN: 0361530801
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 7307199030
- GDS Category Name: Metal Pipe Fittings
- GDS Family Name: Pipe Fittings and Couplings
- GDS Segment Name: Plumbing
- UNSPSC: 40142320
- UNSPSC Class ID: 23
- UNSPSC Commodity Name: Pipe fittings
- UNSPSC Commodity ID: 20
- UNSPSC Commodity Name: Pipe unions
- UNSPSC Family ID: 14
- UNSPSC Family Name: Fluid and gas distribution
- UNSPSC Segment ID: 40
- UNSPSC Segment Name: Distribution and Conditioning Systems and Equipment and Components
Shipping Details
- Not For Sale In: HI AK PR
