Air Cooled Aftercooler, CC1000-3, 1, 569 cfm, 200 hp Max., 2 1/2 in NPT, 230/460V AC, 3 Phase MPN:CC1000-3
This Air Aftercooler from Akg is designed to efficiently cool compressed air for maximum system performance. With a maximum compressor output power of 200 hp and air flow of 1,569 cfm, it's ideal for industrial applications such as manufacturing, construction, and oil and gas. The unit's air-cooled design and aluminum construction ensure reliable operation in temperatures up to 350°F and pressures up to 250 psi. By reducing heat and pressure, the aftercooler extends equipment lifespan and improves productivity, making it a valuable addition to any industrial setting.
Top product features:
- Air cooled design for efficient heat dissipation
- Maximum air flow of 1569 CFM for optimal compressor cooling
- 2 horsepower fan for effective air circulation and temperature reduction
Top product applications:
- Industrial HVAC Systems
- Compressor Cooling Systems
- Oil and Gas Drilling Operations
The AKG CC1000-3 is an air-cooled aftercooler designed for rotary air compressors with a maximum compressor output of 200 hp. Built with an aluminum fin-and-tube core and a steel shell, it helps remove water, oil, and other contaminants from compressed air systems to improve air quality and downstream equipment performance. This unit supports air flow up to 1,569 cfm at 100 psi, operates within a pressure range of 60 to 250 psi, and handles maximum operating temperatures up to 350°F. It features 2 1/2 in. NPT air inlet and outlet connections and includes a 2 hp fan, single-point electrical junction box, and mounting legs for installation.
Key Features:
- - Air-cooled aftercooler for rotary air compressors with maximum 200 hp compressor output
- - Removes water, oil, and contaminants from compressed air systems
- - Maximum air flow capacity of 1,569 cfm at 100 psi
- - Operating pressure range of 60 to 250 psi
- - Maximum operating temperature of 350°F
- - 2 1/2 in. NPT air inlet and outlet connections
- - Aluminum fin-and-tube core construction with steel shell
- - Equipped with a 2 hp fan, 230/460V AC, three-phase, 60 Hz
- - Single-point electrical junction box for simplified electrical connection
- - Includes mounting legs for installation
- - Overall dimensions: 37 in. W x 22 9/16 in. D x 27 11/16 in. H
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 7 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 48.00
- Package Width: 40.00
- Package Height: 33.20
- Package Weight: 240.00
