Shrink Tubing 4 ft Blk 1.1 in ID PK5 MPN:ITCSN-1100-48"-BLACK-5 PCS
Free Shipping
In Stock
Introducing our Heavy Wall Heat Shrink Tubing - an electrical insulation solution that offers outstanding resistance to abrasion and splitting for durability and long-lasting performance. This versatile product is ideal for protecting plugs, connectors, irregular shapes, and wire from harsh environmental conditions such as abrasion and moisture. With its adhesive-lined design, our heat shrink tubing effectively seals and isolates electrical connections while allowing easy installation without the need for additional tools or accessories. Its 4ft length makes it perfect for a variety of applications in various industries, including electronics, automotive, and construction. With its superior performance and reliability, our Heavy Wall Heat Shrink Tubing is the ideal solution to insulate, protect and secure electrical connections in your next project.
Top product features:
- Heavy-wall construction for resistance to splitting and abrasion.
- Adhesive-lined design for sealing electrical connections.
- Available in a 4ft length for versatile applications.
Top product applications:
- Insulation and protection for electrical connections in harsh environments.
- Covering irregularly shaped objects to create a sealed barrier.
- Wrapping wire or cable for added durability and stability.
Technical Specifications
- Item Heat Shrink Tubing
- Tubing Wall Type Heavy Wall
- Material Cross-Linked Polyolefin with Adhesive
- Tubing Flexibility Rigid
- Flame Retardant No
- Adhesive Lined Yes
- Shrink Ratio 3:1
- Use With Wire Size 2 AWG to 4/0 AWG
- I.D. Before Shrinking 1.1 in
- I.D. After Shrinking 0.37 in
- Wall Thickness After Shrinking 0.12 in
- Length 4 ft
- Shrink Tubing Properties Abrasion Resistant, Acid and Alkali Resistant, UV Light Resistant
- Color Black
- Temp. Range -67 Degrees to 230 Degrees F
- Package Style Individual Pieces
- Min. Shrink Temp. 250 Degrees F
- Dielectric Strength 500 V
- Max. Temp. Rating 230 Degrees F
- Min. Temp. Rating -67 Degrees F
- Features Suitable for Insulating Secondary Splices
- Standards CSA File LR38227, RoHS 2011/65/EU, UL 486D
Manufacturer Details
- Manufacturer: 3M
- Condensed Mfg Number: ITCSN110048BLACK5PCS
- MPN: ITCSN-1100-48"-BLACK-5 PCS
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 3926909985
- GDS Category Name: Shrink Tubing
- GDS Family Name: Wire Management
- GDS Segment Name: Electrical
- UNSPSC: 39121711
- UNSPSC Class ID: 17
- UNSPSC Commodity Name: Electrical hardware and supplies
- UNSPSC Commodity ID: 11
- UNSPSC Commodity Name: Tubings
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on November 17, 2023 12:16pm UTC Category: Wire Management
