Shrink Tubing 6 in Blk 0.5 in ID PK10 MPN:EPS300-1/2-6"-BLACK-10-10 PC PKS
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-CXG-30N545
Shrink Tubing 6 in Blk 0.5 in ID PK10
Class XX Master Ring Gages are high precision measuring tools used to accurately measure the internal diameter of cylindrical components with high precision. These gages have an Inner Diameter of 1.0045 Decimal Inches and meet ASME B89.1.6 standards, ensuring their use across various industries such as automotive, aerospace, and medical manufacturing. The #4 wire size provides extra durability while the high precision delivers consistent results. Class XX Master Ring Gages are an essential tool for maintaining quality control in the production process by detecting any deviations from specified dimensions, making them indispensable to industries that require precision and accuracy in their manufacturing processes.
Split-resistant and adhesive-lined heat shrink tubing has a heavy wall that can resist splitting and abrasion. It's typically used in electrical applications. This tubing covers plugs, connectors, irregular shapes, and wire and is heated to shrink the tubing and seal the adhesive.
Technical Specifications
- Item Heat Shrink Tubing
- Tubing Wall Type Thin Wall
- Material Polyolefin with Adhesive
- Tubing Flexibility Flexible
- Flame Retardant Yes
- Adhesive Lined Yes
- Shrink Ratio 3:1
- Use With Wire Size 6 AWG to 1 AWG
- I.D. Before Shrinking 0.5 in
- I.D. After Shrinking 0.16 in
- Wall Thickness After Shrinking 0.03 in
- Length 6 in
- Shrink Tubing Properties Abrasion Resistant, Acid and Alkali Resistant
- Color Black
- Temp. Range -67 Degrees to 230 Degrees F
- Package Style Individual Pieces
- Min. Shrink Temp. 250 Degrees F
- Dielectric Strength 600 V
- Max. Temp. Rating 230 Degrees F
- Min. Temp. Rating -67 Degrees F
- Features Dual-Wall Construction, Moisture Seal Protection, Skintight Fit, Strain Relief Protection, Thermoplastic Adhesive Internal Layer
- Standards CSA File LR38227, UL E157227
Manufacturer Details
- Manufacturer: 3M
- Condensed Mfg Number: EPS300126BLACK1010PCPKS
- MPN: EPS300-1/2-6"-BLACK-10-10 PC PKS
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 3926909985
- GDS Category Name: Shrink Tubing
- GDS Family Name: Wire Management
- GDS Segment Name: Electrical
- UNSPSC: 39121711
- UNSPSC Class ID: 17
- UNSPSC Commodity Name: Electrical hardware and supplies
- UNSPSC Commodity ID: 11
- UNSPSC Commodity Name: Tubings
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Related ASINs: B00C3O405M
Product info last updated on January 25, 2024 1:04pm UTC Category: Wire Management
