Shrink Tubing 250 ft Red 0.187 in ID PK3 MPN:FP301-3/16-250'-RED-SPOOL
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-CXG-2JNA9
Shrink Tubing 250 ft Red 0.187 in ID PK3
The shrink tubing is a high quality polyolefin material offering superior flexibility and durability with a flame retardant rating of UL VW-1 and is RoHS compliant. Available in red color and offered in quantities of 3 per package, it features a minimum inner diameter of 0.187 inches and can be easily cut to the desired length using heat or scissors for applications requiring flexible, abrasion resistance, and insulation on wire harnessing, electrical connections or cable jacketing in a variety of industries such as electronics, automotive and aviation.
Standard heat shrink tubing is used in general purpose industrial and commercial applications. It's flexible to conform to irregular shapes. It covers wire and cable and shrinks with heat to insulate, bundle, color-code, or provide strain relief.
Technical Specifications
- Item Heat Shrink Tubing
- Tubing Wall Type Thin Wall
- Material Polyolefin
- Tubing Flexibility Flexible
- Flame Retardant Yes
- Adhesive Lined No
- Shrink Ratio 2:1
- Use With Wire Size 20 AWG to 18 AWG
- I.D. Before Shrinking 0.19 in
- I.D. After Shrinking 0.09 in
- Wall Thickness After Shrinking 0.02 in
- Length 250 ft
- Shrink Tubing Properties Acid and Alkali Resistant, Solvent Resistant
- Color Red
- Temp. Range -67 Degrees to 275 Degrees F
- Package Style Cut to Length
- Min. Shrink Temp. 212 Degrees F
- Dielectric Strength 600 V
- Max. Temp. Rating 275 Degrees F
- Min. Temp. Rating -67 Degrees F
- Features Balances Electrical, Physical and Chemical Properties, Shrink Fit Protection, Solder Joints, Strain Relief, Terminals and Connections
- Standards CSA Certified, RoHS 2011/65/EU, UL E39100
Manufacturer Details
- Manufacturer: 3M
- Condensed Mfg Number: FP301316250REDSPOOL
- MPN: FP301-3/16-250'-RED-SPOOL
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 3926909988
- GDS Category Name: Shrink Tubing
- GDS Family Name: Wire Management
- GDS Segment Name: Electrical
- UNSPSC: 39121711
- UNSPSC Class ID: 17
- UNSPSC Commodity Name: Electrical hardware and supplies
- UNSPSC Commodity ID: 11
- UNSPSC Commodity Name: Tubings
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Related ASINs: B001CGOBTM, B0BK8LYPF5
Product info last updated on January 25, 2024 1:00pm UTC Category: Wire Management
