Threaded Spring Plunger: 3/8-16, 5/8" Thread Length, 0.186" Dia, 0.11" Projection MPN:52505X
Threaded Spring Plunger: 3/8-16, 5/8" Thread Length, 0.186" Dia, 0.11" Projection
Threaded Spring Plunger: 3/8-16, 5/8 Thread Length, 0.186 Dia, 0.11 Projection is a versatile component used in numerous industrial applications requiring secure and watertight fixings or seals. Manufactured using high-grade stainless steel alloys with precision machining techniques, these plungers ensure consistent pressure distribution across workpieces to provide precise alignment and smooth handling during operation. Offering robust solutions tailored to specific needs, these affordable yet durable parts cater to professional technicians in industries such as automotive, aerospace, hydraulic systems, machining operations, chemical processing plants, and mechanical repair works among others.
Threaded Spring Plunger: 3/8-16, 5/8" Thread Length, 0.186" Dia, 0.11" Projection 40.5 lb Initial End Force, 18.5 lb Final End Force, Steel Body
Product Information
- : 52505X
- Body Length (Decimal Inch): 0.6250
- Body Length (Inch): 5/8
- Body Material: Steel
- Final End Force (Lb.): 18.50
- Finish: Black
- Initial End Force (Lb.): 40.50
- Locking Element: No
- Maximum Plunger Diameter (Decimal Inch): 0.1860
- Nose Material: Delrin
- Plunger Length (Decimal Inch): 0.6250
- Plunger Length (Inch): 5/8
- Plunger Length Type: Short
- Plunger Projection (Decimal Inch): 0.1100
- Thread Length (Decimal Inch): 0.6250
- Thread Length (Inch): 5/8
- Thread Size: 3/8-16
- Tolerance (Decimal Inch): -0.0010 to +0.0000
Additional Information
- Hazardous Materials: No, oK to Ship Via Air
- Material Safety Data Sheet (MSDS) Required: No
- Country of Origin: US, United States
- TAA Compliant: Yes
- UNSPSC: 23251800
- CA Restricted (Prop 65): Unknown
- Package Length: 1.00
- Package Width: 4.00
- Package Height: 2.00
- Package Weight: 1.04
- Prohibited States: AK,HI,PR
Related ASINs: B06XD786Q4, B06XD4J47W, B01LZ1AZZE
Product info last updated on October 9, 2024 1:02pm UTC Category: Spring Plungers, Pins and Stops
