CPMT322ESU T1200A Cermet Turning Insert MPN:19CA115
CPMT322ESU T1200A Cermet Turning Insert
CPMT322ESU T1200A Cermet Turning Insert Uncoated, 3/8" Inscribed Circle, 1/32" Corner Radius, 80degree Diamond
Product Information
- : 19CA115
- Ansi Code: CPMT322ESU
- Chip Breaker: ESU
- Clearance Code: P
- Coating/Finish: Uncoated
- Corner Radius (Decimal Inch): 0.0313
- Corner Radius (Inch): 1/32
- Hole Diameter (Decimal Inch): 0.1732
- Included Angle: 80.0
- Inscribed Circle (Decimal Inch): 0.3750
- Inscribed Circle (Inch): 3/8
- Insert Hand: Neutral
- Insert Holding Method: Screw
- Insert Length (Decimal Inch): 0.3819
- Insert Material: Cermet
- Insert Shape: Diamond
- Insert Shape Code: C
- Insert Size Code: 322
- Insert Style: CPMT
- Insert Thickness (Decimal Inch): 0.1250
- Insert Thickness (Inch): 1/8
- Iso Code: CPMT090308N-SU
- Manufacturer Grade: T1200A
- Primary Workpiece Material: Cast Iron; Stainless Steel; Steel
- Primary Workpiece Material Code: K; M; P
- Rake: Positive
- Rake Angle: 8
- Relief Angle: 11
- Series: CP
- Standards: ANSI; ISO 13399
- Tolerance Code: M
Additional Information
- Hazardous Materials: No, oK to Ship Via Air
- Material Safety Data Sheet (MSDS) Required: No
- Country of Origin: JP, Japan
- TAA Compliant: Yes
- UNSPSC: 23242105
- CA Restricted (Prop 65): Unknown
- Package Length: 3.50
- Package Width: 1.50
- Package Height: 0.44
- Package Weight: 0.01
- Prohibited States: AK,HI,PR
Product info last updated on April 4, 2024 3:39am UTC
Category: Turning and Profiling Inserts
