Industrial Pressure Gauge, 0 to 100 psi, 4 in Dial, 1/4 in NPT, Bottom Location MPN:PFP604WBYG
Industrial Pressure Gauge, 0 to 100 psi, 4 in Dial, 1/4 in NPT, Bottom Location
Monitor and control industrial processes with precision using the Winters Industrial Pressure Gauge. This 4-inch dial gauge measures pressure from 0 to 100 psi with +/-1.0% accuracy, making it ideal for applications in chemical processing, oil and gas, and manufacturing. The 304 stainless steel case and polycarbonate lens ensure durability and visibility, while the liquid-filled design provides vibration resistance. The gauge's NPT connection and bottom location make it easy to integrate into existing systems. With its high accuracy and rugged construction, this gauge is perfect for demanding industrial environments where precise pressure measurement is critical.
Top product features:
- 0 to 100 psi primary pressure range
- Liquid-filled vibration resistance
- Reflective fluorescent yellow-green dial color
Top product applications:
- Industrial pressure gauges are used in oil refineries to monitor the pressure of crude oil in storage tanks.
- Industrial pressure gauges are used in chemical plants to monitor the pressure of chemicals in process vessels.
- Industrial pressure gauges are used in power plants to monitor the pressure of steam in pipes.
Industrial Pressure Gauge, Nominal Dial Size 4 in, Accuracy +/-1.0 Percent, Gauge Case Material 304 Stainless Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Bottom, Case Color Gray, IP/NEMA Rating IP66, NEMA 4X, Primary Pressure Range 0 to 100, Dry Dampening Feature None, Vibration Resistance Liquid-Filled, Dial Color Reflective Fluorescent Yellow-Green
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 93 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.50
- Package Width: 4.00
- Package Height: 2.40
- Package Weight: 1.80
- California Prop 65 Warning: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Product info last updated on March 3, 2026 4:53pm UTC
Category: Pressure and Vacuum Measuring
