Panel-Mount Compound Gauge, 30 to 0 to 300 psi, 4 1/2 in Dial, 1/4 in NPT, Bottom Location MPN:PFP707-DRY-45BF
Panel-Mount Compound Gauge, 30 to 0 to 300 psi, 4 1/2 in Dial, 1/4 in NPT, Bottom Location
This Panel-Mount Compound Gauge is a high-accuracy, 304 stainless steel instrument designed for precise pressure measurement in a variety of industrial applications. With a 4 1/2 inch dial and a range of 30 to 0 to 300 psi, it's ideal for monitoring pressure in hydraulic systems, pneumatic systems, and other high-pressure applications. Its polycarbonate lens and field-fillable design make it a durable and customizable solution. Suitable for use in harsh environments, this gauge meets IP66 and NEMA 4X standards, ensuring reliable performance in demanding conditions. Its compact size and easy installation make it a versatile choice for a range of industries.
Top product features:
- Compound gauge with a 4 1/2 in dial provides a clear and accurate reading of pressure levels.
- The gauge is field fillable, allowing users to adjust the unit of measurement to suit their needs.
- The gauge features a 304 stainless steel case, providing durability and resistance to corrosion.
Top product applications:
- Pressure Testing
- Oil and Gas Industry
- Hydraulic System Monitoring
Panel-Mount Compound Gauge, Nominal Dial Size 4 1/2 in, Accuracy +/-1.0 Percent, Gauge Case Material 304 Stainless Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/4 in, Field Fillable Yes, Process Connection Location Bottom, Case Color Stainless Steel, IP/NEMA Rating IP66, NEMA 4X, Primary Pressure Range 30 to 0 to 300, Dry Dampening Feature None, Vibration Resistance Field-Fillable, Dial Color White
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 93 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.50
- Package Width: 6.50
- Package Height: 3.70
- Package Weight: 1.75
Product info last updated on February 12, 2026 5:25pm UTC
Category: Pressure and Vacuum Measuring
